| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 277-8102 | [1] | SWITCH-ROCKER(24-VOLT) | |
| 2. | 127-2170M | [2] | SCREW-TRUSS HEAD(M8X1.25X20-MM) | |
| 3. | 129-3180M | [1] | LOCKNUT(M12X1.75-THD) | |
| 4. | 8T-4223 | [2] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 5. | 8T-4956M | [1] | BOLT(M12X1.75X35-MM) | |
| 6. | 8T-5062 | [2] | WASHER-PLATED(9X34X2.5-MM THK) | |
| 7. | 8T-6412M | [1] | SCREW-MACHINE(M6X1X20-MM) | |
| M | METRIC PART | |||
