纽荷兰零件查询(D180C XLT) - CRAWLER DOZER - TIER 4A (12/13-) (48.138.AB[07]) - YOKE, TRACK ASSY, ADJUSTER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
271 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 47581144 | [1] | YOKE | BURAssy, Track Adjuster |
| 2. | D95147 | [1] | WIPER SEAL,69.8mm ID x 82.58mm OD x 7.92mm Thk | CASRod Assy |
| 3. | 101-11225 | [1] | SNAP RING,#225, Ext | CAS Superseded by part number: 139504 |
| 4. | 221-29 | [1] | DRAIN PLUG,Sq Hd, 1 1/4"-11 1/2 NPTF | CAS |
| 5. | 219-1 | [1] | LUBE NIPPLE,1/8"-27 x .66 lg | CAS Superseded by part number: 80710 |
| 6. | D35287 | [1] | CHECK VALVE,5/8" - 18 | CASCheck Ball |
| 7. | NSS | [1] | NOT SERVICED SEPARATELY | CONRing, For Service Order Ref. 1 |
