斗山零件查询INTAKE MANIFOLD DX350LC Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
540 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 10. |
65.08201-0066
|
[1] |
MANIFOLD;INTAKE
|
|
| 100. |
65.08202-0179
|
[1] |
STAKE;INTAKE
|
|
| 130. |
65.90201-0126
|
[1] |
BOLT;STUD
|
|
| 140. |
06.06225-0713
|
[7] |
BOLT;STUD
|
|
| 150. |
06.16731-2107
|
[8] |
WASHER
|
|
| 160. |
06.15010-2311
|
[8] |
WASHER
|
|
| 170. |
06.11063-8214
|
[7] |
. NUT
|
|
| 30. |
65.08201-5069
|
[1] |
MANIFOLD;INTAKE
|
|
| 300. |
06.06225-0810
|
[4] |
BOLT;STUD M10X40
|
|
| 310. |
06.16731-2108
|
[4] |
WASHER;SPRING
|
|
| 320. |
06.15010-2312
|
[4] |
WASHER;PLAIN
|
|
| 330. |
06.11063-8215
|
[4] |
NUT;HEX. M10
|
|
| 50. |
06.01923-3219
|
[8] |
BOLT ASS'Y M10X40
|
|
| 60. |
65.08902-0035
|
[2] |
GASKET;INTAKE MANIFOLD
|
|
