纽荷兰零件查询(D75) - CRAWLER DOZER - NA (1/06-) (02-23) - PISTONS - CONNECTING ROD New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
881 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2831298 | [4] | CONNECTING ROD | TORIncl. Ref 2, 3 |
| . . | 2831298R | [4] | REMAN-CONNECTING ROD | TORD75 ( 1/06 - ) |
| . . | 2831298C | [1] | CORE-ROD CONNECTING | TORReturn Number |
| 2. | 4892708 | [1] | BUSHING,38.02mm ID x 41.01mm OD x 33.4mm L | TOR |
| 3. | 2831297 | [2] | FLANGE BOLT,Hex, M10 x 1.25 x 52mm, Cl 10.9 | TOR |
| 4. | 4892714 | [4] | BEARING LINER | TORBEARING, CON. ROD |
| 4. | 4892715 | [4] | BEARING LINER | TORBEARING, CON. ROD |
