现代零件查询14/15/18BR-7 LIFT & TILT HYDRAULIC PIPING(NORMAL)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
747 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
31FG-20110
|
[1] |
CONNECTOR
|
|
| 2. |
X515-109514
|
[1] |
CONNECTOR-LONG,ORFS
|
|
| 3. |
31FS-70040
|
[1] |
CONNECTOR-ORFS
|
|
| 4. |
P930-085037
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 5. |
P930-044042
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 6. |
P930-044039
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 7. |
31FS-70031
|
[1] |
CLAMP-HOSE
|
|
| 8. |
S035-081526
|
[4] |
BOLT-W/WASHER
|
|
| 9. |
31FS-70011
|
[1] |
BRACKET
|
|
| 9. |
31FS-70012
|
[1] |
BRACKET
|
|
| 9. |
31FS-70011
|
[1] |
BRACKET
|
|
| 9. |
31FS-70012
|
[1] |
BRACKET
|
|
| 9. |
31FS-70011
|
[1] |
BRACKET
|
|
| 9. |
31FS-70012
|
[1] |
BRACKET
|
|
| 10. |
31FS-70021
|
[1] |
TUBE
|
|
| 11. |
S491-101402
|
[1] |
PIN-CLEVIS
|
|
| 12. |
S741-100818
|
[2] |
DU BUSHING-FLANGE
|
|
| 12. |
S741-100818
|
[2] |
DU BUSHING-FLANGE
|
|
| 12. |
S741-100818
|
[2] |
DU BUSHING-FLANGE
|
|
| 13. |
S501-100002
|
[1] |
PIN-SELF LOCKING
|
|
