纽荷兰零件查询(D75) - CRAWLER DOZER - NA (1/06-) (09-29) - CAB - GLASS AND WINDOWS (SIAC CAB WITH STATIONARY SIDE REAR WINDOW) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
1006 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87400649 | [1] | CAB GLASS | BURFront |
| 2. | 87400651 | [1] | CAB GLASS | BURRight-Hand Side |
| 3. | 87400650 | [1] | CAB GLASS | BURLeft-Hand Side |
| 4. | 76067468 | [1] | CAB GLASS | LECRear |
| 5. | 76067477 | [4] | CLIP | LEC |
| 6. | 14305334 | [4] | HEX SOC SCREW,M6 x 20mm, Cl 10.9, Full Thd | LEC Superseded by part number: 14305324 |
| 7. | 76079203 | [1] | WINDOW FRAME | BURRight-Hand Side |
| 8. | 76079204 | [1] | WINDOW FRAME | BURLeft-Hand Side |
