| 1. |
84394712
|
[1] |
TAILGATE
|
NH
Incl 36
|
| 2. |
87045740
|
[2] |
PLATE
|
PA
Tailgate Pivot Superseded by part number: 47798992
|
| 3. |
84216964
|
[1] |
LATCH
|
NH
LH Superseded by part number: 47748162
|
| 4. |
84216997
|
[1] |
LATCH
|
NH
RH
|
| 5. |
84217007
|
[2] |
HOOK
|
NH
LH, RH
|
| 6. |
9706685
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 7. |
140046
|
[2] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 8. |
84480737
|
[2] |
BUSHING,35.17mm ID x 41.35mm OD x 50mm L
|
NH
M41 OD x 35 ID x 50 Long
|
| 9. |
86572215
|
[2] |
SPRING,Extension, 25.58mm OD x 240.18mm L
|
NH
M28 OD x 20 ID x 240 Long
|
| 10. |
34019
|
[1] |
SPRING,Compression, 9/16" OD x 2-5/16" L
|
GI
2-5/16" Long
|
| 11. |
87665527
|
[2] |
SPACER,25.75mm ID x 31.75mm OD x 28mm L
|
NH
M31 OD x 25 ID
|
| 12. |
84277390
|
[1] |
ROD
|
PLO
|
| 13. |
87399
|
[6] |
COTTER PIN,1/2 x 3 Bolt
|
GI
|
| 14. |
88182
|
[2] |
COTTER PIN,1/4" OD x 2" L
|
NH
|
| 15. |
80756
|
[1] |
COTTER PIN,1/8" x 3/4"
|
NH
|
| 16. |
166065
|
[2] |
PIN,25.4mm OD x 66.5mm L
|
NH
M25.4 Dia. x 66 Long
|
| 17. |
9845448
|
[1] |
PIN,31.7mm OD x 83.7mm L
|
NH
M31.7 Dia. x 83 Long
|
| 18. |
374835
|
[10] |
BOLT,Hex, M16 x 2 x 40mm, Cl 10.9, Full Thd
|
BHB
|
| 19. |
328754
|
[2] |
CARRIAGE BOLT,M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 20. |
11106231
|
[6] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9
|
LEC
|
| 21. |
9622795
|
[2] |
PLATE
|
PA
Superseded by part number: 86636768, 89622795
|
| 22. |
285072
|
[6] |
WASHER,10.3mm ID x 22.2mm OD x 2.7mm Thk
|
NH
|
| 23. |
273127
|
[10] |
WASHER,16.67mm ID x 28.57mm OD x 7.37mm Thk
|
NH
M28.5 OD x 16.6 ID
|
| 24. |
86603125
|
[4] |
WASHER,40.54mm ID x 60.33mm OD x 4.8mm Thk
|
NH
M60.3 OD x 40.6 ID
|
| 25. |
86636633
|
[2] |
WASHER,42.86mm ID x 57.15mm OD x 1.52mm Thk
|
NH
M57.1 OD x 42.8 ID
|
| 26. |
80702
|
[2] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 27. |
87367
|
[2] |
WASHER,1.06" ID x 2" OD x 0.13" Thk
|
PA
|
| 28. |
9635082
|
[4] |
NUT,5/16" - 18, Gr 5
|
NH
|
| 29. |
83918746
|
[2] |
WASHER,0.34" ID x 0.69" OD x 0.07" Thk
|
FOR
Superseded by part number: 44722S36
|
| 30. |
87709056
|
[1] |
CHANNEL
|
NH
|
| 31. |
86624468
|
[1] |
SPACER,1.65" L x 5/16” Thk
|
NH
Switch
|
| 32. |
86594422
|
[1] |
SENSOR
|
NH
Tailgate
|
| 33. |
87310126
|
[2] |
SCREW,Phillips Drive, Pan HD, #10 - 24 x 3/4", SST
|
BUR
|
| 34. |
86900323
|
[2] |
NUT,#10 - 24
|
PA
KWH #10 Stainless Steel
|
| 35. |
27953
|
[2] |
EYEBOLT
|
NH
5/16"-18 x 6-1/4"
|
| 36. |
86547781
|
[2] |
REFLECTOR,RED
|
NH
|
| 36. |
86516139
|
[2] |
CAUTION DECAL
|
NH
|
