| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84410618
|
[1] |
HITCH
|
NH
Incl 19 - 20
|
| 2. |
47523516
|
[1] |
CLEVIS
|
NH
Cast Superseded by part number: 47795882
|
| 2. |
47795882
|
[1] |
CLEVIS
|
NH
Steel
|
| 6. |
115680
|
[2] |
HOOK
|
NH
|
| 7. |
362573
|
[1] |
BOLT,Hex, M16 x 150mm, Cl 8.8
|
NH
|
| 8. |
273672
|
[1] |
FASTENER
|
NH
|
| 9. |
64053
|
[20] |
WASHER,16.9mm ID x 38.55mm OD x 4mm Thk
|
NH
Superseded by part number: 80064053, 86528652
|
| 10. |
120092
|
[10] |
BOLT,M16 x 70mm, Cl 8.8
|
NH
|
| 11. |
86000441
|
[13] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 12. |
86607695
|
[1] |
SPACER,17.48mm ID x 28.6mm OD x 20.6mm L
|
NH
|
| 13. |
636422
|
[1] |
WASHER,16.66mm ID x 69.85mm OD
|
NH
|
| 14. |
321246
|
[2] |
BOLT,Hex, M16 x 2 x 120mm, Cl 8.8
|
NH
|
| 15. |
84368723
|
[1] |
SUPPORT
|
PLO
|
| 16. |
9804279
|
[2] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 17. |
9804266
|
[2] |
BOLT,Hex, M12 x 25mm, Cl 8.8, Full Thd
|
DUB
|
| 18. |
130358
|
[6] |
WASHER,16.28mm ID x 38.35mm OD x 4.11mm Thk
|
NH
|
| 19. |
47361278
|
[1] |
DANGER DECAL
|
NH
|
| 20. |
47361285
|
[1] |
WARNING DECAL
|
NH
540 RPM Models
|
| 20. |
47361283
|
[1] |
DANGER DECAL
|
NH
1000 RPM Models
|
