纽荷兰零件查询(D85B) - CRAWLER DOZER TIER 3 (3/08-) (04-09) - HARNESS, ENGINE (RIGHT-HAND SIDE) - ALTERNATOR/STARTER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
305 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 86992395 | [1] | STARTER MOTOR,12V, 2.7kW | TORSee Figure 04-01 |
| 2. | 86992395R | [1] | REMAN-STARTER,12V, 2.7kW | TORReman for New PN 86992395 |
| 2. | 86992395C | [1] | CORE-STARTER,12V, 2.7kW | TORReturn Number |
| 3. | 345-158 | [1] | SEALANT | BRR |
| 6. | 87422777 | [1] | ALTERNATOR,12V, 90A, W/ Pulley | IMOSee Figure 04-02 |
| 6. | 87422777R | [1] | REMAN-ALTERNATOR | IMO12V, 90A |
| 6. | 87422777C | [1] | CORE-ALTERNATOR | IMOReturn Number |
| 9. | 614-12025 | [1] | BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8, Full Thd | IH Superseded by part number: 300388 |
| 11. | 892-11012 | [1] | LOCK WASHER,M12 | CAS Superseded by part number: 412123 |
| 22. | 87678223 | [1] | WIRE | BURWIRE/A, Serial Range: Starter-Alternator |
| 24. | L126713 | [2] | BOOT | CASElectrical |
| 25. | L18331 | [3] | CABLE TIE,375.9mm L | CAS Superseded by part number: 529070 |
| 26. | L71188 | [1] | CLAMP,15.75mm ID, 13.46mm Bolt Hole, P Type | CAS |
