凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (60.220.AU[01]) - VAR - 726821 - PICK-UP WHEEL ASSY BOLTED Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
285 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84194676
|
[1] |
SUPPORT
|
NH
|
| 2. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Tire and Wheel
|
| 3. |
714411
|
[1] |
COLLAR
|
PA
Superseded by part number: 86634544
|
| 4. |
26130
|
[2] |
WASHER,26mm ID x 35mm OD x 1.7mm Thk
|
NH
|
| 5. |
603373
|
[1] |
JAM NUT,Slotted, 1" - 14, Gr 2
|
NH
Superseded by part number: 143183
|
| 6. |
87398
|
[1] |
COTTER PIN,3/16" OD x 1-1/4" OAL
|
NH
|
| 7. |
80043480
|
[1] |
BOLT
|
PA
|
| 8. |
140046
|
[2] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 9. |
9706685
|
[1] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 10. |
9706693
|
[1] |
BOLT,M12 x 60mm, Cl 8.8
|
NH
|
