凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (60.220.AU[04]) - CASTER PICK-UP WHEEL Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
118 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87055177
|
[2] |
WHEEL ASSY.
|
PA
& Tire, Incl 2 - 10 Superseded by part number: 87055161, 86611311, 279538, 200734, 136376, 132710, 132709
|
| 2. |
86611311
|
[1] |
TYRE/TIRE
|
PA
|
| 3. |
87055161
|
[1] |
RIM
|
PA
Incl 10
|
| 4. |
279538
|
[1] |
TUBE
|
NH
|
| 5. |
200734
|
[1] |
HUB CAP
|
NH
|
| 6. |
132710
|
[2] |
BEARING CONE,25.4mm ID x 14.73mm W
|
NH
|
| 7. |
132709
|
[2] |
BEARING CUP,50.29mm OD x 10.67mm W
|
NH
|
| 8. |
136376
|
[1] |
SEAL,31.75mm ID x 50.42mm OD x 6.75mm Thk
|
NH
|
| 9. |
714411
|
[1] |
COLLAR
|
PA
Superseded by part number: 86634544
|
| 10. |
NH80715
|
[1] |
LUBE NIPPLE
|
NH
|
