| 1. |
84541913
|
[1] |
ARM
|
NH
LH
|
| 2. |
84541910
|
[1] |
ARM
|
NH
RH
|
| 3. |
84599271
|
[1] |
WINDGUARD
|
NH
|
| 4. |
47361097
|
[2] |
SPACER,20mm ID x 34.9mm OD x 31mm L
|
NH
|
| 5. |
84563993
|
[2] |
SPACER,10.31mm ID x 18.24mm OD x 33.53mm L
|
NH
|
| 6. |
84492976
|
[2] |
FLAP
|
NH
Superseded by part number: 47461801
|
| 7. |
9827956
|
[2] |
WASHER,10.3mm ID x 25.4mm OD x 2.67mm Thk
|
NH
|
| 8. |
412151
|
[2] |
BOLT,M10 x 1.5 x 61.58mm, Cl 8.8
|
NH
Superseded by part number: 73161469
|
| 9. |
100037
|
[6] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 10. |
84238738
|
[2] |
SPACER,10.34mm ID x 15.88mm OD x 12mm L
|
NH
|
| 11. |
80702
|
[8] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 12. |
9804262
|
[2] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 13. |
9804278
|
[4] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 14. |
213404
|
[2] |
SPACER,10.3mm ID x 38.1mm OD x 5.2mm OAL
|
NH
|
| 15. |
120068
|
[2] |
BOLT,Hex, M10 x 40mm, Cl 8.8
|
NH
|
| 16. |
698748
|
[2] |
BUSHING,10.3mm ID x 15.88mm OD x 9.53mm L
|
NH
Superseded by part number: 626698
|
| 17. |
9804261
|
[4] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 18. |
235126
|
[4] |
WASHER,10.3mm ID x 38mm OD x 1.7mm Thk
|
NH
|
| 19. |
47400899
|
[2] |
CHAIN
|
NH
|
| 20. |
88546
|
[2] |
BOLT,Hex, 3/8" - 16 x 2 1/4", Gr 5
|
NH
|
| 21. |
9637692
|
[2] |
NUT,3/8"-16, GB
|
NH
|
| 22. |
84511590
|
[1] |
WINDGUARD
|
NH
|
| 23. |
87036413
|
[2] |
SPACER,10.34mm ID x 15.88mm OD x 23.8mm L
|
CAS
|
| 24. |
47467993
|
[2] |
RETAINER
|
NH
|
| 25. |
86507486
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 26. |
9804277
|
[4] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 27. |
86512426
|
[2] |
CARRIAGE BOLT,Sq Nk, M10 x 50mm, Cl 8.8
|
WIN
|
