凯斯零件查询(8460) - CASE IH ROUND BALER (BEFORE S/N CFH0057418) (1/88-12/93) (140) - ANALYZER, SYSTEM SERVICE KIT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
288 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700122725
|
[1] |
TOOL ASSY.
|
HFI
ANALYZER - system service kit complete
|
| 1. |
700707294
|
[2] |
PUSH-ON NUT
|
CAS
WELL NUT - rubber Superseded by part number: 694147
|
| 2. |
700122758
|
[1] |
HANDLE
|
HFI
|
| 3. |
NS
|
[1] |
NOT SERVICED
|
BAS
ANALYZER - system
|
| 4. |
700710407
|
[1] |
MANUAL - OPERATORS
|
|
| 5. |
700710584
|
[1] |
DECAL
|
CAS
- instruction
|
| . . |
7703457
|
[2] |
HYD CONNECTOR,Hex, 1/4" - 20 x 3/4", Gr 5
|
NNA
1/4-20 x 3/4 C Superseded by part number: 413-412, 413-412, 86516954
|
