现代零件查询14/16BRJ-7 REACH CYLINDEREPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
319 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31HJ-03012
|
[1] |
CYLINDER ASSY
|
|
| . |
31HJ-03030
|
[1] |
CYLINDER ASSY
|
|
| . |
31HJ-03022
|
[1] |
CYLINDER ASSY
|
|
| . |
31HJ-03040
|
[1] |
CYLINDER ASSY
|
|
| 1. |
XKCD-01068
|
[1] |
TUBE ASSY
|
|
| 1. |
XKCD-01065
|
[1] |
TUBE ASSY
|
|
| 2. |
XKCD-01051
|
[1] |
SPHERICAL BEARING
|
|
| 3. |
XKCD-01052
|
[1] |
RETAINING RING
|
|
| 4. |
XKCD-01051
|
[1] |
SPHERICAL BEARING
|
|
| 5. |
XKCD-01052
|
[1] |
RETAINING RING
|
|
| 6. |
XKCD-01066
|
[1] |
ROD ASSY
|
|
| 7. |
XKCD-01054
|
[1] |
ROD COVER
|
|
| 8. |
XKCD-01055
|
[1] |
ROD BUSH
|
|
| K9. |
XKCD-01056
|
[1] |
U-PACKING
|
|
| K10. |
XKCD-01057
|
[1] |
BACK UP RING
|
|
| K11. |
XKCD-01058
|
[2] |
DUST WIPER
|
|
| K12. |
XKCD-01059
|
[1] |
O-RING
|
|
| K13. |
XKCD-01060
|
[1] |
BACK UP RING
|
|
| K14. |
XKCD-00691
|
[1] |
O-RING
|
|
| 15. |
XKCD-01061
|
[1] |
PISTON
|
|
| K16. |
XKCD-00725
|
[1] |
SEAL-PISTON
|
|
| K17. |
XKCD-01062
|
[1] |
O-RING
|
|
| 18. |
XKCD-01063
|
[1] |
HEX NUT
|
|
| K. |
XKCD-01069
|
[1] |
SEAL KIT
|
|
