凯斯零件查询(8460) - CASE IH ROUND BALER (BEFORE S/N CFH0057418) (1/88-12/93) (022) - GEARBOX, SERIAL NUMBER CFH0016501 THROUGH CFH0016551 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
930 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
6500540
|
[1] |
GEARBOX
|
CAS
COMPLETE - primary (S.N. CFH0016501 thru CFH0016551) Superseded by part number: 700709190
|
| 1. |
6501803
|
[2] |
SHAFT
|
CAS
|
| 2. |
6500581
|
[2] |
CAP ASSY.
|
HFI
CAP ASSEMBLY (with cup and seal)
|
| 3. |
806968
|
[1] |
GASKET
|
CAS
- .002
|
| . . |
806943
|
[1] |
GASKET
|
IH
- .005
|
| . . |
806935
|
[1] |
GASKET
|
IH
- .015
|
| 4. |
7744543
|
[2] |
SEAL
|
CAS
SEAL - oil
|
| 5. |
7710106
|
[2] |
DIFFERENTIAL
|
CAS
BEARING CUP Superseded by part number: 73124678
|
| 6. |
7710114
|
[2] |
BEARING
|
CAS
CONE Superseded by part number: 73124678
|
| 7. |
800334
|
[2] |
ROLLER BEARING,29.38 mm ID x 25.433 mm
|
HFI
BEARING CONE
|
| 8. |
800342
|
[2] |
BEARING CUP,66.421 mm OD x 19.05 mm
|
CAS
CUP Superseded by part number: 86900791
|
| 9. |
6502157
|
[1] |
GEAR
|
CAS
MATCHED SET OF GEARS (20-tooth and 27-tooth)
|
| 10. |
861211
|
[2] |
KEY
|
HFI
- special
|
| 11. |
6501795
|
[2] |
WASHER
|
CAS
- special Superseded by part number: 700709419
|
| 12. |
6500607
|
[1] |
TRANSFER BOX
|
HFI
BOX ASSEMBLY (with bearing cup)
|
| 13. |
700700048
|
[2] |
O-RING
|
CAS
(5.714 I.D.)
|
| 14. |
846642
|
[1] |
BUSHING
|
CAS
1/2 NPFT x 1/8 NPTF, reducer bushing
|
| . . |
700708349
|
[2] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8, Full Thd
|
CAS
M10 x 1.5 x 25 hex cap screw grade 5 Superseded by part number: 11106231
|
| . . |
700708350
|
[16] |
SCREW
|
CAS
M10 x 1.5 x 30 hex cap screw grade 5 Superseded by part number: 43140
|
| . . |
700702319
|
[16] |
SCREW
|
CAS
10 HELICAL SPRING LOCK WASHER
|
