纽荷兰零件查询(D95B) - CRAWLER DOZER TIER 3 (3/08-) (02-37) - INTAKE MANIFOLD New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
725 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2855805 | [1] | INLET MANIFOLD | TOR Superseded by part number: |
| 2. | 4895432 | [1] | SCREW | TOR |
| 3. | 4899039 | [6] | BOLT,Flng, M8 x 1.25 x 25mm, Cl 10.9 | TOR |
| 4. | 2855809 | [1] | MANIFOLD | TOR |
| 5. | 4899921 | [1] | GASKET,1.2mm Thk | TOR |
| 6. | 2854702 | [6] | SCREW,Hex Flg, M6 x 20mm | TORM6 x 20 Superseded by part number: 16585870 |
| 7. | 2852295 | [2] | SCREW | TORM8 x 40 Superseded by part number: 16586725 |
| 7. | 2852267 | [2] | FLANGE BOLT,Hex, M8 x 1.25 x 90mm | TOR Superseded by part number: 16598224 |
| 8. | 2854700 | [1] | COVER | TOR Superseded by part number: 504114351 |
| 9. | 2854701 | [1] | GASKET,0.8mm Thk | TOR Superseded by part number: 504114491 |
