| 1. |
700116206
|
[1] |
SPECIAL BOLT
|
IH
DRAWBOLT
|
| 2. |
7746555
|
[2] |
ELBOW
|
CAS
90 deg. ELBOW WITH O-RING Superseded by part number: 76344
|
| 3. |
700707390
|
[1] |
HYDRAULIC HOSE,6.35 mm ID x 2475.00 mm, SAE 100R1
|
CAS
6.35 mm ID x 2475.00 mm, SAE 100R1 Superseded by part number: 700710983, 265235
|
| 4. |
700707410
|
[1] |
CYLINDER
|
CAS
- hydraulic, threader (S.N. CFH0016501 thru CFH0017432) Superseded by part number: 700712122
|
| . . |
700709416
|
[1] |
CYLINDER
|
CAS
- hydraulic, threader (S.N. CFH0017433 and on) Superseded by part number: 700712122
|
| 5. |
700707389
|
[1] |
HYDRAULIC HOSE,6.35 mm ID x 2275.00 mm, SAE 100R1
|
CAS
6.35 mm ID x 2275.00 mm, SAE 100R1
|
| 6. |
863498
|
[2] |
CLEVIS PIN
|
CAS
5/8 x 3-1/2 CLEVIS PIN (S.N. CFH0016501 thru CFH0016838)
|
| 7. |
7030695
|
[1] |
PLUG
|
CAS
- pump
|
| 8. |
700117735
|
[1] |
ADHESIVE STRIP
|
CAS
TRIM - edge
|
| 9. |
700116123
|
[2] |
CLAMP
|
HFI
|
| 10. |
6501076
|
[1] |
SPACER
|
HFI
|
| 11. |
756486
|
[1] |
CLAMP
|
HFI
- line Superseded by part number: 9827902
|
| 12. |
7720055
|
[1] |
HOSE CLAMP
|
CAS
CLAMP - hose Superseded by part number: 507586
|
| 13. |
700707396
|
[1] |
HOSE ASSY.
|
CAS
HOSE - hydraulic with o-ring
|
| 14. |
7846801
|
[1] |
ELBOW,45 Degree, 3/4"-16, 37 Degree x 3/4"-16, O-Ring
|
CAS
45 deg. ELBOW WITH O-RING Superseded by part number: 216797
|
| 15. |
700707384
|
[1] |
TUBE ASSY.,25.4 mm OD, 850, 400 mm Length
|
HFI
LINE - hydraulic
|
| 16. |
7746753
|
[1] |
ADAPTER
|
CAS
FLARED CONNECTOR WITH O-RING Superseded by part number: 86512926
|
| 17. |
700706367
|
[1] |
HYDRAULIC PUMP
|
HFI
PUMP - radial piston
|
| 18. |
700707387
|
[2] |
HYDRAULIC HOSE,6.35 mm ID x 1825.00 mm, SAE 100R1
|
CAS
6.35 mm ID x 1825.00 mm, SAE 100R1
|
| 19. |
279706
|
[2] |
O-RING
|
PA
|
| 20. |
312801
|
[2] |
SPACER
|
CAS
Superseded by part number: 320993R1
|
| 21. |
846170
|
[2] |
ELBOW
|
CAS
90 deg. ELBOW Superseded by part number: 578384
|
| 22. |
7075625
|
[1] |
CYLINDER
|
L
- hydraulic, pickup Superseded by part number: 700726495
|
| 23. |
254-409
|
[2] |
SPACER
|
|
| 24. |
700117736
|
[1] |
ADHESIVE STRIP
|
CAS
TRIM - edge Superseded by part number: 700117735
|
| 25. |
738468
|
[2] |
O-RING
|
IH
|
| 26. |
738484
|
[2] |
O-RING
|
IH
Superseded by part number: 167266
|
| 27. |
7040397
|
[4] |
O-RING
|
IH
Superseded by part number: 165202
|
| 28. |
7899966
|
[1] |
STRAP
|
CAS
TIE - cable Superseded by part number: 529070
|
| 29. |
700119118
|
[1] |
SPACER
|
HFI
|
| 30. |
700708944
|
[1] |
HYDRAULIC HOSE,6.35 mm ID x 1875.00 mm, SAE 100R1
|
CAS
6.35 mm ID x 1875.00 mm, SAE 100R1 Superseded by part number: 97478C1, 84384
|
| . . |
7703507
|
[1] |
DECAL,Hex, 5/16" - 18 x 2", Gr 5
|
CAS
5/16-18 x 2 C Superseded by part number: 413-532, 413-532, NLS
|
| . . |
7704205
|
[1] |
3/8-16 x 3 C
|
HYDRAULIC VALVE
|
| . . |
703561
|
[1] |
BOLT,Hex, 5/8" - 11 x 2 3/4", Gr 5
|
CAS
5/8-11 x 2-3/4 C Superseded by part number: 413-1044
|
| . . |
7701683
|
[1] |
BOLT,Hex, 5/8" - 11 x 3", Gr 5
|
CAS
5/8-11 C Superseded by part number: 87338
|
| . . |
705632
|
[1] |
WASHER
|
CAS
5/8 NP Superseded by part number: 495-11066, 495-11066, 87365
|
