| 1. |
7746555
|
[2] |
ELBOW
|
CAS
90 deg. ELBOW WITH O-RING Superseded by part number: 76344
|
| 2. |
738468
|
[2] |
O-RING
|
IH
|
| 3. |
700707390
|
[1] |
HYDRAULIC HOSE,6.35 mm ID x 2475.00 mm, SAE 100R1
|
CAS
6.35 mm ID x 2475.00 mm, SAE 100R1 Superseded by part number: 700710983, 265235
|
| 4. |
700707389
|
[1] |
HYDRAULIC HOSE,6.35 mm ID x 2275.00 mm, SAE 100R1
|
CAS
6.35 mm ID x 2275.00 mm, SAE 100R1
|
| 5. |
700707410
|
[1] |
CYLINDER
|
CAS
- hydraulic, threader Superseded by part number: 700712122
|
| . . |
700709416
|
[1] |
CYLINDER
|
CAS
- hydraulic, threader Superseded by part number: 700712122
|
| 6. |
700116206
|
[1] |
SPECIAL BOLT
|
IH
DRAWBOLT
|
| 7. |
700117736
|
[1] |
ADHESIVE STRIP
|
CAS
TRIM - edge Superseded by part number: 700117735
|
| 8. |
863498
|
[2] |
CLEVIS PIN
|
CAS
5/8 x 3-1/2 CLEVIS PIN
|
| 9. |
254409
|
[2] |
SPACER
|
HFI
|
| 10. |
7075625
|
[1] |
CYLINDER
|
L
- hydraulic, pickup Superseded by part number: 700726495
|
| 11. |
700119118
|
[1] |
SPACER
|
HFI
|
| 12. |
312801
|
[2] |
SPACER
|
CAS
Superseded by part number: 320993R1
|
| 13. |
700707387
|
[1] |
HYDRAULIC HOSE,6.35 mm ID x 1825.00 mm, SAE 100R1
|
CAS
6.35 mm ID x 1825.00 mm, SAE 100R1
|
| 14. |
700708944
|
[1] |
HYDRAULIC HOSE,6.35 mm ID x 1875.00 mm, SAE 100R1
|
CAS
6.35 mm ID x 1875.00 mm, SAE 100R1 Superseded by part number: 97478C1, 84384
|
| 15. |
846170
|
[2] |
ELBOW
|
CAS
90 deg. ELBOW Superseded by part number: 578384
|
| 16. |
700117735
|
[1] |
ADHESIVE STRIP
|
CAS
TRIM - edge
|
| 17. |
700116123
|
[2] |
CLAMP
|
HFI
|
| 18. |
756486
|
[1] |
CLAMP
|
HFI
- line Superseded by part number: 9827902
|
| 19. |
7720055
|
[1] |
HOSE CLAMP
|
CAS
CLAMP - hose Superseded by part number: 507586
|
| 20. |
6501076
|
[1] |
SPACER
|
HFI
|
| 21. |
700709241
|
[1] |
HYDRAULIC HOSE,12.70 mm ID x 1400.00 mm, SAE 100R1
|
CAS
12.70 mm ID x 1400.00 mm, SAE 100R1
|
| 22. |
7846801
|
[1] |
ELBOW,45 Degree, 3/4"-16, 37 Degree x 3/4"-16, O-Ring
|
CAS
45 deg. ELBOW WITH O-RING Superseded by part number: 216797
|
| 23. |
279706
|
[1] |
O-RING
|
PA
|
| 24. |
7037799
|
[1] |
O-RING,14-1, 90 Duro, 1.048" ID x .116" Thk
|
CAS
Superseded by part number: 70921886
|
| 25. |
700708938
|
[1] |
FITTING
|
CAS
CONNECTOR WITH O-RING, flared Superseded by part number: 9615397
|
| 26. |
700708999
|
[1] |
TUBE,25.4 mm OD, 783, 400 mm Length
|
CAS
LINE - hydraulic
|
| 27. |
738484
|
[1] |
O-RING
|
IH
Superseded by part number: 167266
|
| 28. |
700708580
|
[1] |
PUMP
|
CAS
- hydraulic, piston
|
| 29. |
722470
|
[1] |
MOUNTING CLIP
|
CAS
TIE - cable Superseded by part number: 529070
|
| 30. |
700118716
|
[3] |
WASHER
|
CAS
- special, S.N. CFH0017433 and on
|
| 31. |
700709533
|
[1] |
ORIFICE
|
CAS
S.N. CFH0017433 and on Superseded by part number: H757815
|
| . . |
413-532
|
[1] |
BOLT,Hex, 5/16" - 18 x 2", Gr 5
|
CAS
5/16-18 x 2 C Superseded by part number: 9636711
|
| . . |
703603
|
[2] |
SCREW
|
CAS
3/8-16 x 1-1/2 C
|
| . . |
413-648
|
[1] |
BOLT,Hex, 3/8" - 16 x 3", Gr 5
|
CAS
3/8-16 x 3 C Superseded by part number: 280161
|
| . . |
703561
|
[1] |
BOLT,Hex, 5/8" - 11 x 2 3/4", Gr 5
|
CAS
5/8-11 x 2-3/4 C Superseded by part number: 413-1044
|
| . . |
7703819
|
[1] |
5/8-11 x 31/4 C
|
|
| . . |
703632
|
[2] |
5/8 NP
|
|
