凯斯零件查询(8460) - CASE IH ROUND BALER (BEFORE S/N CFH0057418) (1/88-12/93) (110) - CYLINDER, HYDRAULIC, PICKUP AND THREADER, CYLINDER NUMBER 700707410 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
259 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700707410
|
[1] |
CYLINDER
|
CAS
COMPLETE - hydraulic, pickup (S.N. CFH0016501 thru CFH0017432) Superseded by part number: 700712122
|
| . . |
700709416
|
[1] |
CYLINDER
|
CAS
COMPLETE - hydraulic, pickup (S.N. CFH0017433 and on) Superseded by part number: 700712122
|
| 1. |
700707303
|
[1] |
TUBE ASSY.
|
HFI
BARREL
|
| 2. |
700707304
|
[1] |
LOCK NUT
|
HFI
5/8-18 LOCKNUT
|
| 3. |
700707305
|
[1] |
PISTON
|
CAS
|
| 4. |
700707306
|
[1] |
GLAND
|
HFI
- head
|
| 5. |
700707302
|
[1] |
PISTON ROD
|
HFI
ROD - piston
|
| . . |
700707308
|
[1] |
SEAL KIT
|
HFI
SEAL AND O-RING REPAIR KIT, Includes items in art marked with asterisk
|
