凯斯零件查询(8460) - CASE IH ROUND BALER (BEFORE S/N CFH0057418) (1/88-12/93) (118) - HYDRAULIC ASSEMBLY, LEFT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
209 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
7795487
|
[1] |
HOSE
|
HFI
- hydraulic
|
| 2. |
700118823
|
[2] |
PIN
|
IH
|
| 3. |
7746555
|
[3] |
ELBOW
|
CAS
90 deg. ELBOW WITH O-RING Superseded by part number: 76344
|
| 4. |
700708068
|
[2] |
CLEVIS PIN,15.77mm OD x 68.66mm L
|
IH
5/8 x 2-1/2 CLEVIS PIN
|
| 5. |
738468
|
[7] |
O-RING
|
IH
|
| 6. |
700708797
|
[1] |
HEX SOC SCREW
|
CAS
1/2-13 x 2-1/4 SHOULDER SCREW
|
| 7. |
700709959
|
[1] |
BREATHER
|
CAS
|
| 8. |
7796287
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 9. |
700707391
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 10. |
8046658
|
[1] |
TEE
|
CAS
WITH O-RING Superseded by part number: 86513020
|
| 11. |
700707261
|
[1] |
CYLINDER
|
CAS
- HYDRAULIC, tailgate
|
| 12. |
7796204
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 13. |
700707399
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 14. |
700707262
|
[3] |
CYLINDER
|
CAS
- hydraulic Superseded by part number: 700712161
|
| 15. |
700707276
|
[1] |
HOSE
|
CAS
- hydraulic
|
| . . |
7883382
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 120M
|
CAS
3/8-16 x 1 HWHMS Superseded by part number: 87034804
|
| . . |
704742
|
[1] |
ROD
|
NNA
1/2-13 HFTLN Superseded by part number: 231-5348, 231-5348, 86516877
|
