纽荷兰零件查询(D95B) - CRAWLER DOZER TIER 3 (3/08-) (03-11) - FUEL INJECTION SYSTEM - DRAIN LINE New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
834 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 87731172 | [1] | ENGINE ASSEMBLY,73kW, 4.5L, 4 Cylinders, W/ Turbocharger | BURENGINE ASSY ENGINE ASSY., 97 hp (72 kw), 4 Cyl. Engine; Includes Parts On Figures 02-10 - 02-41, 03-06 - 03-13 |
| 1. | 2855336 | [1] | RETURN PIPE | TORIncl. Ref. 2 Superseded by part number: |
| 2. | 4894095 | [3] | O-RING,2.5mm Thk x 8mm ID, 60 Duro | TOR |
| 3. | 4896329 | [1] | PRESSURE RELIEF VALVE | TOR |
| 4. | 4896996 | [1] | CLAMP | TOR |
