凯斯零件查询(8460) - CASE IH ROUND BALER (BEFORE S/N CFH0057418) (1/88-12/93) (070) - SHIELDS, SIDE, ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
682 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700114084
|
[2] |
STRAP
|
HFI
|
| 2. |
700115994
|
[1] |
SUPPORT
|
HFI
- front, shield
|
| 3. |
700116000
|
[1] |
STRAP
|
HFI
- left
|
| 4. |
700115986
|
[4] |
HINGE
|
HFI
- shield, rear
|
| 5. |
700117070
|
[1] |
SHIELD
|
CAS
left, rear
|
| 6. |
700116002
|
[1] |
DOOR
|
CAS
- left
|
| 7. |
7025075
|
[2] |
BRACKET
|
CAS
- hook
|
| 8. |
700115984
|
[4] |
HINGE
|
HFI
- door
|
| 9. |
700117082
|
[2] |
SUPPORT
|
HFI
|
| 10. |
700115991
|
[1] |
SUPPORT
|
HFI
- jack
|
| 11. |
700117071
|
[1] |
PANEL
|
CAS
- left, front
|
| 12. |
776682
|
[2] |
HOOK
|
CAS
- rubber Superseded by part number: 86975220
|
| 13. |
700115999
|
[3] |
SUPPORT
|
HFI
- shield
|
| 14. |
776674
|
[2] |
SUPPORT
|
L
ANCHOR - hook
|
| 15. |
63784
|
[2] |
CLEVIS PIN
|
IH
1/4 x 1-1/2 CLEVIS Superseded by part number: 141-13
|
| 16. |
700115977
|
[1] |
STRAP
|
HFI
- corner
|
| 17. |
700116001
|
[1] |
STRAP
|
HFI
brace
|
| 18. |
S120261
|
[2] |
PIN
|
CAS
.149 HAIRPIN COTTER
|
| 19. |
700117079
|
[2] |
LATCH
|
HFI
- lower
|
| 20. |
700117080
|
[2] |
CHANNEL
|
HFI
- reinforcement
|
| 21. |
700116028
|
[2] |
SUPPORT
|
HFI
- door
|
| 22. |
700116003
|
[1] |
DOOR
|
CAS
- right
|
| 23. |
763565
|
[2] |
PIN
|
CAS
5/16 x 2 clevis pin Superseded by part number: 439-5532
|
| 24. |
700117078
|
[2] |
SUPPORT
|
CAS
ROD - detent
|
| 25. |
754606
|
[2] |
SPRING
|
CAS
- compression
|
| 26. |
700117083
|
[2] |
STRAP
|
HFI
- brace
|
| 27. |
700117074
|
[1] |
SHIELD
|
HFI
- right, rear Superseded by part number: 700131973
|
| 28. |
700117081
|
[4] |
SPACER
|
HFI
|
| . . |
7883325
|
[67] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
7883333
|
[2] |
BOLT,Hex, 5/16" - 18 x 1", Gr 120M
|
CAS
5/16-18 x 1 HWHMS Superseded by part number: 121-108
|
| . . |
7883358
|
[4] |
SCREW,Hex Washer, 5/16" - 18 x 1 1/2"
|
CAS
5/16-18 x 1-1/2 HWHMS Superseded by part number: 163-56
|
| . . |
700704837
|
[4] |
SCREW,Cross Pan Hd, #10-24 x 3/8"
|
CAS
NO. 10-24 x 3/8 CRPHMS Superseded by part number: 72181877
|
