卡特零件查询（725C） 370-5521: BAFFLE GP-RADIATOR
广数供应链运营团队, 14 02月, 2025，浏览：
761 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 362-4583 | [1] | BAFFLE(TOP) | |
| 2. | 365-4218 | [1] | BAFFLE AS | |
| 3. | 383-1397 | [1] | GUARD | |
| 4. | 393-2256 | [1] | BAFFLE(RH) | |
| 5. | 393-2257 | [1] | BRACKET | |
| 6. | 5C-7261M | [4] | NUT(M8X1.25-THD) | |
| 7. | 7X-0579 | [21] | WASHER-HARD(8.8X25.5X2-MM THK) | |
| 8. | 7X-7729 | [2] | WASHER(11X25X3-MM THK) | |
| 9. | 8T-4189M | [17] | BOLT(M8X1.25X20-MM) | |
| 10. | 8T-4195M | [2] | BOLT(M10X1.5X30-MM) | |
| 11. | 201-4066D | | SEAL(0.9-M EACH) | |
| 12. | 222-5093E | | SEAL(26-CM) | |
| 12A. | 222-5093E | | SEAL(19-CM) | |
| 13. | 136-7728D | | SEAL(1-M EACH) | |
| 13A. | 136-7728D | | SEAL(1.01-M) | |
| 13B. | 136-7728D | | SEAL(0.2-M) | |
| | D | | ORDER BY THE METER |
| | E | | ORDER BY THE CENTIMETER |
| | M | | METRIC PART |
