神钢零件查询(FD6(T)14) - NISSAN DIESEL ENGINE ASN 050001 - LK400 & LK500A (1/06-12/06) (06-006) - FAN "BRACKET" Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
275 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-10. | VG21101Z5502 | [1] | U-BRACKET | KOBBRACKET-FAN,FOR A1 ONLY |
| 1. | VG21047Z5501 | [1] | U-BRACKET | KOBBKACKET-FAN PULLEY,FOR A1 ONLY |
| 2. | VG21048Z5500 | [1] | SHAFT | KOBSHAFT,FOR A1 ONLY |
| 3. | VG21053Z5502 | [1] | HUB | KOBHUB-PULLEY,FOR A1 ONLY |
| 4. | VG21103Z5502 | [1] | BALL BEARING | KOBBEAKING-BALL,FOR A1 ONLY |
| 5. | VG21103Z5503 | [1] | BALL BEARING | KOBBEARING-BALL,FOR A1 ONLY |
| 6. | VG0092211700 | [1] | SNAP RING | KOBRING-SNAP,FOR A1 ONLY |
| 7. | VG0891514610 | [1] | WASHER-SPRING WASHER-SPRING,FOR A1 ONLY | WASHER-SPRING WASHER-SPRING,FOR A1 ONLY |
| 8. | VG0891124610 | [1] | NUT N/A SUB'D NUT,FOR A1 ONLY | NUT N/A SUB'D NUT,FOR A1 ONLY |
| 9. | VG0092225200 | [1] | SNAP RING | KOBRING-SNAP,FOR A1 ONLY |
| 10. | VG0093210100 | [1] | FITTING | KOBNIPPLE-GREASE,FOR A1 ONLY |
| 11. | VG0812089010 | [2] | SCREW | KOBBOLT GEAR CASE,FOR A2 ONLY |
| 11. | VG0812080010 | [1] | SCREW | KOBBOLT,FOR A1 ONLY |
| 12. | VG0812080110 | [1] | BOLT BOLT,FOR A1 ONLY | BOLT BOLT,FOR A1 ONLY |
| 13. | VG0891513810 | [2] | WASHER SPRING WASHER-SPRING | WASHER SPRING WASHER-SPRING |
| 14. | VG0812083528 | [2] | BOLT HEX BOLT,W/WASHER,FOR A1 ONLY | BOLT HEX BOLT,W/WASHER,FOR A1 ONLY |
