神钢零件查询(FD6(T)14) - NISSAN DIESEL ENGINE ASN 050001 - LK400 & LK500A (1/06-12/06) (06-013) - COOLER-OIL (FITTING PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
760 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VG21300Z5501 | [1] | COOLER ASSY-OIL (INNER PARTS E2138) | |
| 2. | VG21310Z5501 | [1] | GASKET | KOBGASKET-OIL COOLER Superseded by part number: VG2131095500 |
| 3. | VG0813083010 | [9] | BOLT | |
| 4. | VG0813084010 | [2] | BOLT,FOR A1,A2 ONLY | |
| 5. | VG0013083510 | [1] | BOLT,FOR A1,A2 ONLY | |
| 6. | VG0891513810 | [12] | WASHER SPRING WASHER-SPRING,FOR A1,A2 ONLY | WASHER SPRING WASHER-SPRING,FOR A1,A2 ONLY |
| 7. | VG0891543810 | [1] | WASHER WASHER-PLAIN,FOR A2 ONLY | WASHER WASHER-PLAIN,FOR A2 ONLY |
| 8. | VG15068Z5503 | [1] | PIPE OIL PIPE-OIL | PIPE OIL PIPE-OIL |
| 9. | VG2130661520 | [5] | RING | KOBO-RING |
| 10. | VG0811082502 | [4] | BOLT,W/WASHER | |
| 11. | VG0811086002 | [1] | BOLT,W/WASHER | |
| 12. | VG0811082562 | [1] | BOLT BOLT,W/WASHER | BOLT BOLT,W/WASHER |
| 13. | VG0811080110 | [1] | BOLT | |
| 14. | VG0891513810 | [1] | WASHER SPRING WASHER-SPRING | WASHER SPRING WASHER-SPRING |
