| 1. |
84600588
|
[1] |
ROLL
|
NH
Backwrap, Steel, Incl 21
|
| 1. |
86536001
|
[1] |
ROLLER
|
NH
Backwrap, Rubber, Incl 21
|
| 2. |
87534991
|
[1] |
STRIP
|
NH
|
| 3. |
9608117
|
[1] |
SHAFT
|
NH
Superseded by part number: 87023401
|
| 4. |
87048815
|
[1] |
ANGLE
|
NH
|
| 5. |
86636769
|
[1] |
SCRAPER BLADE
|
NH
|
| 6. |
86557580
|
[1] |
ROLLER
|
NH
Follower, Incl 19
|
| 7. |
86553395
|
[2] |
SUPPORT
|
NH
|
| 8. |
87398962
|
[2] |
HUB,12.5mm ID x 47.42mm OD x 13.2mm L
|
PA
|
| 9. |
86521602
|
[2] |
SUPPORT
|
NH
Superseded by part number: 87023400
|
| 10. |
43140
|
[4] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 11. |
412087
|
[2] |
BOLT,Hex, M12 x 1.75 x 45mm, Cl 10.9, Full Thd
|
BHB
Superseded by part number: 86639031
|
| 12. |
43260
|
[2] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 10.9, Full Thd
|
BHB
|
| 13. |
280519
|
[10] |
SELF-TAP SCREW,Hex, 5/16" - 12 x 1"
|
NH
|
| 14. |
9804258
|
[10] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 15. |
322
|
[20] |
WASHER,8.73mm ID x 42.07mm OD x 3.43mm Thk
|
NH
|
| 16. |
65319
|
[1] |
WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk
|
NH
|
| 17. |
29684
|
[2] |
WASHER,13.5mm ID x 50.8mm OD x 5.52mm Thk
|
NH
|
| 18. |
322358
|
[10] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 19. |
86553396
|
[2] |
BEARING ASSY,30.23mm ID x 90mm OD x 30.2mm W, SQUARE BORE
|
NH
Inc 20
|
| 20. |
86548282
|
[2] |
BALL BEARING,29.41mm ID x 90mm OD x 30.2mm W, Square Bore
|
NH
|
| 21. |
84259867
|
[2] |
BALL BEARING,38.1mm ID x 80mm OD x 22mm W
|
PLO
|
