卡特零件查询（725C） 364-5174: FENDER GP
广数供应链运营团队, 14 02月, 2025，浏览：
241 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 185-3794 | [2] | DEFLECTOR | |
| 2. | 206-5017 | [17] | SPACER(11X20X5-MM THK) | |
| 3. | 376-9778 | [1] | PLATE | |
| 4. | 376-9779 | [2] | PLATE | |
| 5. | 376-9804 | [2] | PLATE AS | |
| | | | (EACH INCLUDES) |
| | 8T-3490M | [4] | NUT-WELD(M10X1.5-THD) | |
| 6. | 376-9821 | [1] | PLATE-COVER | |
| 7. | 376-9825 | [1] | COVER(FENDER, RH) | |
| 8. | 376-9826 | [1] | COVER(FENDER, LH) | |
| 9. | 378-3583 | [1] | PLATE | |
| 10. | 378-3603 | [1] | PLATE AS | |
| | 8T-3490M | [4] | NUT-WELD(M10X1.5-THD) | |
| 11. | 388-0865 | [1] | PLATE | |
| 12. | 388-0969 | [2] | PLUG | |
| 13. | 465-2867 | [1] | FENDER AS(LH) | |
| 14. | 417-3637 | [10] | SPACER(11X22X75.5-MM THK) | |
| 15. | 424-1785 | [6] | STEP | |
| 16. | 425-5763 | [2] | PLATE AS | |
| | | | (EACH INCLUDES) |
| | 8T-3490M | [2] | NUT-WELD(M10X1.5-THD) | |
| 17. | 465-1959 | [1] | SUPPORT AS(RH) | |
| 18. | 465-1960 | [1] | SUPPORT AS(LH) | |
| 19. | 441-8634 | [1] | PLATE | |
| 20. | 441-8638 | [1] | PLATE | |
| 21. | 465-2866 | [1] | FENDER AS(RH) | |
| 22. | 198-4778 | [3] | WASHER-HARD(13.5X30X12-MM THK) | |
| 23. | 5P-1076 | [7] | WASHER-HARD(13.5X30X4-MM THK) | |
| 24. | 091-0081 | [8] | SPACER(10.5X20X10-MM THK) | |
| 25. | 7X-2538M | [10] | BOLT(M8X1.25X100-MM) | |
| 26. | 8T-0389M | [24] | LOCKNUT(M10X1.5-THD) | |
| 27. | 8T-4121 | [53] | WASHER-HARD(11X21X2.5-MM THK) | |
| 28. | 8T-4122 | [6] | WASHER-HARD(17X32X3.5-MM THK) | |
| 29. | 8T-4183M | [6] | BOLT(M12X1.75X40-MM) | |
| 30. | 8T-4186M | [32] | BOLT(M10X1.5X40-MM) | |
| 31. | 8T-4195M | [29] | BOLT(M10X1.5X30-MM) | |
| 32. | 8T-4224 | [10] | WASHER-HARD(8.8X16X2-MM THK) | |
| 33. | 8T-6868M | [4] | BOLT(M12X1.75X80-MM) | |
| 34. | 8T-7338M | [6] | BOLT(M16X2X45-MM) | |
| 35. | 7X-7729 | [8] | WASHER(11X25X3-MM THK) | |
| | M | | METRIC PART |
