| 1. |
84406459
|
[1] |
SPROCKET
|
PLO
Triple, 18T, 13T, 18T, RC80
|
| 2. |
87032323
|
[1] |
SPROCKET
|
PA
22T and Clutch Half, Incl 33
|
| 3. |
84421259
|
[1] |
SPROCKET,RC80, 25T
|
PLO
25T, RC80
|
| 4. |
86609558
|
[1] |
BEARING ASSY,45mm ID
|
NH
M45 Bore
|
| 5. |
84354241
|
[1] |
SPROCKET
|
PLO
25T, RC80 and 17T, RC60, Starter Roll
|
| 5. |
84594720
|
[1] |
SPROCKET,27T Internal, 16T/16T/25T External
|
NH
25T, RC80 and 16T RC60, Starter Roll
|
| 6. |
86618109
|
[1] |
SPROCKET
|
NH
29T, RC80 and 35T, RC50
|
| 7. |
80717
|
[1] |
LUBE NIPPLE,45 Degree, 1/8" NPT x 7/8" lg
|
NH
|
| 8. |
84262617
|
[1] |
ARM
|
NH
Idler, Incl 35, Serial Range: -YFN188618 Superseded by part number: 47748078
|
| 8. |
47748078
|
[1] |
ARM
|
NH
Idler, Incl 35 , Start Serial: YFN188619
|
| 9. |
84401598
|
[2] |
SPROCKET,39.967mm ID x 118.4mm OD x 14.61mm Thk
|
GI
13T, RC80, Incl 34 Superseded by part number: 87011880
|
| 10. |
47687089
|
[1] |
EYEBOLT
|
NH
3/8"-16 x 8.83"
|
| 11. |
87028608
|
[1] |
CLUTCH
|
NH
|
| 12. |
9829364
|
[1] |
CAP COVER
|
NH
|
| 13. |
691873
|
[1] |
ELBOW,90 Degree Elbow, 1/8" Male NPT x 1/8" Female NPT
|
NH
Swivel 90° Superseded by part number: 219-416
|
| 14. |
45440
|
[1] |
SNAP RING,#162, Ext
|
GI
|
| 15. |
86640119
|
[1] |
SPRING,Compression, 2.438" OD x 4.5" L
|
NH
M2.438" OD 4.50" Long
|
| 16. |
87483
|
[1] |
KEY,0.31" x 1.5" L
|
NH
Square, .31" x 1.50"
|
| 17. |
58821
|
[6] |
WASHER,45.24mm ID x 56.36mm OD x 1.65mm Thk
|
NH
M56.3 OD x 45.2 ID
|
| 18. |
80299
|
[4] |
WASHER,0.69" ID x 1.75" OD x 0.13" Thk
|
NH
|
| 19. |
26402
|
[2] |
WASHER,25.8mm ID x 38.1mm OD x 1.7mm Thk
|
NH
|
| 20. |
692300
|
[1] |
WASHER,13.5mm ID x 50.8mm OD x 7.37mm Thk
|
NH
M50.8 OD x 13.5 ID
|
| 20. |
694478
|
[1] |
WASHER,13.5mm ID x 57.15mm OD x 4.8mm Thk
|
NH
M57.1 OD x 13.5 ID
|
| 21. |
80702
|
[1] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 22. |
9808110
|
[2] |
WASHER,46mm ID x 60mm OD x 1.64mm Thk
|
NH
M60 OD x 46 ID
|
| 24. |
86000441
|
[1] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 25. |
9628503
|
[2] |
NUT,3/8"-16, G5
|
NH
|
| 26. |
9804279
|
[4] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 27. |
9671487
|
[4] |
BOLT,Hex, M12 x 50mm, Cl 8.8
|
PA
|
| 28. |
120092
|
[1] |
BOLT,M16 x 70mm, Cl 8.8
|
NH
|
| 29. |
86512547
|
[1] |
SPRING,Extension, 1.94" OD x 13 - 1/8" L
|
NH
M1.940" OD x 13-1/8" Long
|
| 30. |
86618213
|
[1] |
SPECIAL BOLT,M12 x 40mm, Drilled
|
NH
Drilled, CSHH M12 x 40
|
| 31. |
9804268
|
[1] |
BOLT,Hex, M12 x 40mm, Cl 8.8, Full Thd
|
NH
|
| 31. |
9670066
|
[1] |
FLANGE BOLT,Hex, M12 x 30mm, Cl 8.8
|
NH
|
| 33. |
86977429
|
[2] |
BUSHING,44.62mm ID x 50.93mm OD x 22.2mm L
|
PA
M50.9 OD x 44.6 ID x 22 Long
|
| 34. |
66553
|
[1] |
BALL BEARING,16.13mm ID x 40mm OD x 12.12mm W
|
NH
|
| 35. |
84019797
|
[1] |
SLEEVE,25mm ID x 28mm OD x 25mm L
|
NH
M25 ID x 25 Long Superseded by part number: 604085
|
