| 1. | 201-307 | [1] | ELBOW,90º, 1 3/16"-12 x 1 1/16"-12 Adj, ORFS | CASIncl. Ref 2, 3 Superseded by part number: 9846848 |
| 2. | 237-6012 | [1] | O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro | CASBoss End Superseded by part number: 72186120, 167266, 79051113 |
| 3. | 238-6018 | [1] | O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro | CASFace Seal End Superseded by part number: 9991976 |
| 4. | 430380A1 | [1] | HOSE ASSY. | BUR1590 mm (62-5/8 in); Control Valve To Thermal Bypass Valve |
| 5. | 201-129 | [2] | HYD CONNECTOR,1-3/16" - 12 ORFS x 1-5/16" - 12 ORB | CASIncl. Ref 6, 7 Superseded by part number: 87359470 |
| 6. | 237-6016 | [1] | O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro | CASBoss End Superseded by part number: 72186238, 167268 |
| 8. | R46908 | [1] | VALVE | CASThermal Bypass Valve; See Figure 08-04 |
| 9. | 87301279 | [2] | CARRIAGE BOLT,Sht Sq Nk, M10 x 90mm, Cl 8.8 | WIC |
| 10. | 895-18010 | [2] | WASHER,10.5mm ID x 18mm OD x 1.6mm Thk | CAS Superseded by part number: 86625251 |
| 12. | 832-10410 | [2] | NUT,M10 x 1.5, Cl 8 | CAS Superseded by part number: 190003888452 |
| 13. | 201-355 | [1] | ELBOW,1-3/16" - 12 ORFS x 1-5/16" - 12 ORB | CASIncl. Ref 14, 15 Superseded by part number: 87326965 |
| 16. | 430381A1 | [1] | HOSE ASSY. | BUR1900 mm (74-13/16 in); Tank Filter To Thermal Bypass Valve |
| 17. | 201-407 | [1] | TEE,1 7/16"-12 x 1 5/16"-12 Run, ORFS | IHIncl. Ref 18, 19 |
| 19. | 238-6021 | [2] | O-RING,0.07" Thk x 0.926" ID, -21, Cl 6, 90 Duro | CASFace Seal End Superseded by part number: 87473574 |
| 20. | 87733797 | [1] | HOSE ASSY. | BURHOSE ASSY., 2140 mm (84-5/16 in); Thermal Bypass Valve To Cooler |
| 24. | 87733803 | [1] | HOSE ASSY. | BURHOSE ASSY., 2075 mm (81-3/4 in); Cooler To Thermal Bypass Valve |
| 25. | 87313817 | [3] | CONDUIT | BURSleeve |
| 26. | L18331 | [2] | CABLE TIE,375.9mm L | CASUsed To Attach Sleeve Superseded by part number: 529070 |
| 28. | 242999A1 | [2] | CLAMP | CAS |
| 29. | 811-12040 | [2] | CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 40mm, Cl 8.8 | CAS Superseded by part number: 328754 |
| 31. | 832-10412 | [2] | NUT,M12 x 1.75, Cl 8 | CAS Superseded by part number: 87780366, 412126 |
| 36. | 426336A1 | [1] | FILTER ASSY | BURSee Figure 06-09 |
| 37. | 614-10020 | [4] | BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd | CAS Superseded by part number: 43138 |
| 38. | 895-11010 | [4] | WASHER,11mm ID x 20mm OD x 2mm Thk | CAS Superseded by part number: 14496621 |
| 39. | 201-105 | [1] | HYD CONNECTOR,1 7/16"-12 ORFS x 1 5/16"-12 ORB | IHIncl. Ref 40, 41 Superseded by part number: 9824055 |
| 42. | 201-393 | [1] | ELBOW,90º, 1 7/16"-12 Adj x 1 7/16"-12 Fem Sw, ORFS | BRRIncl. Ref 43, 44 |
