| 1. |
84399830
|
[1] |
SUPPORT
|
PLO
|
| 2. |
84134373
|
[1] |
DECAL
|
NH
Control Valve
|
| 3. |
84603722
|
[1] |
DECAL
|
NH
Density Pressure
|
| 4. |
84384411
|
[1] |
PRESSURE GAUGE,3000 PSI, 1/4" NPT
|
PLO
|
| 5. |
241971
|
[1] |
HYD CONNECTOR,9/16"-18, 37 Degree x 1/4"-18, Fem Pipe
|
PA
|
| 6. |
32406
|
[4] |
SPACER,25.9mm ID x 31.5mm OD x 16.8mm L
|
NH
|
| 7. |
47887741
|
[4] |
LINK,467mm L
|
NH
|
| 8. |
768624
|
[2] |
SPACER
|
PA
Superseded by part number: 86636659
|
| 9. |
86515940
|
[2] |
PIN,38.1mm OD x 91.5mm L
|
PA
Superseded by part number: 86637228
|
| 10. |
86566989
|
[4] |
CABLE TIE,208mm L
|
ZED
|
| 11. |
1589857
|
[2] |
CLAMP
|
BER
|
| 12. |
9671714
|
[1] |
FLANGE BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 13. |
86629542
|
[4] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 14. |
87034173
|
[7] |
CABLE TIE,774.7mm L
|
PA
Superseded by part number: 529070
|
| 15. |
529828
|
[1] |
GROMMET,2 1/8" x 2 7/8" x 2 1/2"
|
NH
|
| 16. |
84292754
|
[1] |
CLIP,Cable Tie W/ Fir Tree, 5mm OD x 203mm OAL
|
NH
|
| 17. |
86010402
|
[3] |
CLAMP,12.7mm, Coat, 10.3mm Bolt Hole, P Type
|
NH
|
| 18. |
381014
|
[2] |
SCREW,Flng, M8 x 16mm
|
NH
|
| 19. |
86511842
|
[2] |
BOLT,M8 x 1.25 x 48.1mm OAL, Cl 8.8
|
NH
|
| 20. |
425520
|
[3] |
RIVET,Pop, 3.96mm OD x 10.4mm L
|
NH
|
| 21. |
87000230
|
[2] |
PLATE
|
GI
|
| 22. |
120061
|
[2] |
BOLT,Hex, M8 x 60mm L, Cl 8.8
|
NH
|
| 23. |
9804264
|
[2] |
FLANGE BOLT,M10 x 50mm, 26mm Thd, Cl 8.8
|
NH
Superseded by part number: 16587625
|
| 24. |
100037
|
[2] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 25. |
87367
|
[4] |
WASHER,1.06" ID x 2" OD x 0.13" Thk
|
PA
|
| 26. |
87399
|
[3] |
COTTER PIN,1/2 x 3 Bolt
|
GI
|
| 27. |
87400
|
[4] |
COTTER PIN,3/16" x 2"
|
WIN
|
| 28. |
28581
|
[8] |
WASHER,38.9mm ID x 60.3mm OD x 3.5mm Thk
|
NH
Superseded by part number: 86611730
|
| 29. |
87654704
|
[2] |
SPRING
|
PLO
Assembly
|
| 30. |
9617265
|
[2] |
BAND
|
NH
|
| 31. |
9617266
|
[2] |
BEARING CAP,145.6 mm OD
|
PA
Superseded by part number: 86636552
|
| 32. |
226131
|
[1] |
PIVOT
|
NH
Superseded by part number: 87654703
|
| 33. |
9846489
|
[1] |
SPRING,Compression, 1.81" OD x 9.44" L
|
NH
|
| 34. |
625098
|
[2] |
PIVOT
|
NH
|
| 35. |
633038
|
[2] |
THREADED ROD,3/4" - 10 x 11-1/2" L
|
NH
|
| 36. |
86511191
|
[2] |
WASHER,0.81" ID x 2" OD x 0.15" Thk
|
NH
|
| 37. |
280954
|
[2] |
NUT,3/4"-10, G5
|
NH
|
| 38. |
257163
|
[2] |
WASHER,25.4mm ID x 50.8mm OD x 4.17mm Thk
|
NH
|
| 39. |
9804268
|
[4] |
BOLT,Hex, M12 x 40mm, Cl 8.8, Full Thd
|
NH
|
| 40. |
87364
|
[4] |
WASHER,0.53" ID x 1.06" OD x 0.1" Thk
|
NH
|
| 41. |
86619803
|
[4] |
FLANGE NUT
|
NH
|
| 42. |
9849647
|
[1] |
NUT,7/8"-9, G5
|
NH
|
| 43. |
87314
|
[1] |
JAM NUT,Jam, 7/8"-9, G2
|
NH
|
