沃尔沃零件查询EL70 VOLVO BM Refuelling pumpVOLVO BM EL70 NoneNone92488Autodata Volvo online
广数供应链运营团队, 14 02月, 2025，浏览：
369 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
VOE11009860
|
[1] |
Anchorage
|
|
| 2. |
VOE11009861
|
[1] |
Fuel pump
|
|
| |
|
[1] |
Switchbox assembl.
|
24V
|
| |
|
[1] |
Fuse
|
10amp
|
| |
VOE11998689
|
[1] |
Repair kit
|
|
| 3. |
VOE13945444
|
[2] |
Screw
|
|
| 4. |
VOE13945408
|
[2] |
Nut
|
|
| 5. |
VOE11009868
|
[1] |
Pipe
|
|
| 6. |
VOE11009872
|
[REQ] |
Hose
|
L = 630MM
|
| 7. |
VOE943475
|
[6] |
Hose clamp
|
|
| 8. |
VOE11009872
|
[REQ] |
Hose
|
L = 1230MM
|
| 9. |
VOE14016673
|
[REQ] |
Strip clamp
|
|
| 10. |
VOE931440
|
[2] |
Nipple
|
|
| 11. |
VOE11009143
|
[1] |
Clamp
|
|
| 12. |
VOE13945408
|
[2] |
Nut
|
|
| 13. |
VOE4821833
|
[2] |
Nipple
|
|
| 14. |
VOE11043022
|
[2] |
Nipple
|
|
| 15. |
VOE11147586
|
[1] |
Dust cover
|
|
| 16. |
VOE11043021
|
[1] |
Sleeve
|
|
| 17. |
VOE11147585
|
[1] |
Dust cover
|
|
| 18. |
VOE11009872
|
[REQ] |
Hose
|
L = 3000MM
|
| 19. |
VOE11009873
|
[1] |
Strainer
|
|
| 20. |
VOE1585404
|
[1] |
Fitting
|
|
| 21. |
VOE11009871
|
[1] |
Wire harness
|
CY
|
| 22. |
VOE13948996
|
[1] |
Insulator
|
|
| 23. |
VOE14016673
|
[REQ] |
Strip clamp
|
|
| 24. |
VOE13948995
|
[1] |
Pin housing
|
|
| 25. |
VOE965824
|
[2] |
Cable terminal
|
|
| 26. |
VOE954453
|
[REQ] |
El Cable
|
R
|
| 27. |
VOE970624
|
[REQ] |
El Cable
|
SB
|
| 28. |
VOE185507
|
[REQ] |
Plastic hose
|
|
| 29. |
VOE956958
|
[2] |
Splice
|
|
| 30. |
VOE969423
|
[2] |
Six point socket screw
|
|
| 31. |
VOE60110304
|
[2] |
Washer
|
|
| 32. |
VOE13949278
|
[2] |
Flange lock nut
|
|
