| 1. |
84134471
|
[1] |
CHANNEL
|
NH
|
| 2. |
47662020
|
[2] |
ANGLE
|
NH
, Serial Range: -YFN188618 Superseded by part number: 47819695
|
| 2. |
47819695
|
[2] |
ANGLE
|
NH
, Start Serial: YFN188619
|
| 3. |
47572067
|
[1] |
ARM
|
NH
, Serial Range: -YFN188618 Superseded by part number: 47797761
|
| 3. |
47797755
|
[1] |
ARM
|
NH
, Start Serial: YFN188619
|
| 4. |
84134469
|
[1] |
BLOCK
|
NH
, Serial Range: -YFN188618 Superseded by part number: 47781564
|
| 4. |
47781564
|
[1] |
BLOCK
|
NH
, Start Serial: YFN188619
|
| 5. |
84545260
|
[1] |
SLIDE
|
NH
|
| 6. |
84590444
|
[1] |
PLATE
|
NH
|
| 7. |
84158034
|
[1] |
PLATE
|
NH
, Serial Range: -YFN188618 Superseded by part number: 47819696
|
| 7. |
47819696
|
[1] |
PLATE
|
NH
, Start Serial: YFN188619
|
| 8. |
84158032
|
[2] |
SLIDE
|
NH
|
| 9. |
47630705
|
[1] |
SHAFT
|
NH
|
| 10. |
47481777
|
[1] |
HOOK
|
NH
|
| 11. |
86559592
|
[2] |
SPRING,Extension, 0.99" OD x 6-1/4" L
|
NH
|
| 12. |
84146982
|
[4] |
BEARING, ROLLER, CYL
|
NH
Bearing
|
| 13. |
9808171
|
[2] |
SPACER,12mm ID x 19mm OD x 7mm Thk
|
PA
Superseded by part number: 86636890
|
| 14. |
103243
|
[1] |
DRIVEN SPROCKET
|
NH
18T
|
| 15. |
47596314
|
[1] |
SPACER
|
NH
|
| 16. |
9617629
|
[1] |
CHAIN,41 Links x 12.7mm Pitch = 520.7mm L
|
NH
Single Pitch, Non Hardened Pins, Serial Range: -YFN188618 Superseded by part number: 569088R91X, 242-138
|
| 16. |
47799278
|
[1] |
CHAIN,41 Links x 12.7mm Pitch = 520.7mm L
|
NH
Single Pitch,Hardened Pins, Incl 52, Start Serial: YFN188619
|
| 17. |
86624729
|
[1] |
ARM
|
NH
Incl 53
|
| 18. |
87715757
|
[1] |
LEVER
|
NH
Superseded by part number: 84534787
|
| 19. |
768703
|
[2] |
BUSHING,10.31mm ID x 15.88mm OD x 11.13mm L
|
NH
|
| 20. |
86636763
|
[2] |
HUB
|
NH
|
| 21. |
87398
|
[1] |
COTTER PIN,3/16" OD x 1-1/4" OAL
|
NH
|
| 22. |
86629541
|
[1] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 23. |
280466
|
[1] |
CARRIAGE BOLT,Short Sq Nk, 5/8" - 11 x 2 1/2", Gr 5
|
NH
|
| 24. |
86512446
|
[10] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 25. |
331168
|
[1] |
BOLT,Hex, M10 x 1.5 x 140mm, Cl 8.8
|
NH
|
| 26. |
374892
|
[1] |
CARRIAGE BOLT,M10 x 1.5 x 40mm, Cl 8.8
|
NH
, Serial Range: -YFN188618
|
| 26. |
87682394
|
[1] |
CARRIAGE BOLT,M10 x 1.5 x 40mm, Cl 10.9
|
CAS
, Start Serial: YFN188619
|
| 27. |
120068
|
[1] |
BOLT,Hex, M10 x 40mm, Cl 8.8
|
NH
, Serial Range: -YFN188618
|
| 27. |
43248
|
[1] |
BOLT,Hex, M10 x 1.5 x 40mm, Cl 10.9
|
NH
, Start Serial: YFN188619
|
| 28. |
9804263
|
[2] |
BOLT,M10 x 49.2mm, Cl 8.8
|
NH
, Serial Range: -YFN188618
|
| 28. |
9804264
|
[2] |
FLANGE BOLT,M10 x 50mm, 26mm Thd, Cl 8.8
|
NH
, Start Serial: YFN188619 Superseded by part number: 16587625
|
| 29. |
86729275
|
[1] |
LOCK WASHER,5/8 0.634 CST ZND
|
BHB
|
| 30. |
235126
|
[2] |
WASHER,10.3mm ID x 38mm OD x 1.7mm Thk
|
NH
|
| 31. |
86511323
|
[6] |
WASHER,10.5mm ID x 20mm OD x 2mm Thk
|
NH
Superseded by part number: 14496621
|
| 32. |
134463
|
[1] |
WASHER,.030" Thk
|
NH
|
| 33. |
87367
|
[2] |
WASHER,1.06" ID x 2" OD x 0.13" Thk
|
PA
|
| 34. |
9706685
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 35. |
280474
|
[2] |
NUT,7/16"-20, GC
|
NH
|
| 36. |
280374
|
[1] |
NUT,Hex, 5/8" - 11, Gr 5
|
NH
|
| 37. |
9804278
|
[13] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 38. |
9804277
|
[4] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 39. |
300483
|
[1] |
SET SCREW,M10 x 25mm
|
PA
, Serial Range: -YFN188618
|
| 39. |
81763
|
[1] |
SET SCREW,Hex Soc, 3/8"-16 x 1"
|
GI
, Start Serial: YFN188619
|
| 40. |
14442131
|
[4] |
SCREW,Flat Csk Hd, M8 x 1.25 x 25mm, Cl 10.9
|
FOR
, Serial Range: -YFN188618 Superseded by part number: 14442134
|
| 41. |
80702
|
[2] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
, Start Serial: YFN188619
|
| 41. |
87363
|
[2] |
WASHER,0.47" ID x 0.92" OD x 0.07" Thk
|
NH
|
| 42. |
81547
|
[2] |
LOCK WASHER,7/16"
|
NH
|
| 43. |
47532701
|
[1] |
STIFFENER
|
NH
|
| 43. |
87364
|
[1] |
WASHER,0.53" ID x 1.06" OD x 0.1" Thk
|
NH
|
| 44. |
84303
|
[1] |
LUBE NIPPLE,1/8"-27 NPT x 1" lg, Fem
|
GI
Superseded by part number: 86050275
|
| 45. |
65319
|
[1] |
WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk
|
NH
|
| 46. |
87365
|
[3] |
WASHER,0.66" ID x 1.31" OD x 0.1" Thk
|
NH
|
| 47. |
11787
|
[1] |
FITTING,3/8"-24 Fem x 1/8" NPT
|
NH
Superseded by part number: 84341119, 84341119, 87426476
|
| 48. |
87014413
|
[1] |
TUBE,4.80 mm OD x 1850 mm L
|
PA
|
| 49. |
48564
|
[3] |
90 ELBOW,90 Degree, 11/16" x 5/8", 1/8" NPT
|
NH
|
| 50. |
86580291
|
[1] |
ADAPTER,1/8" - 27 x 1/4" - 28
|
NH
|
| 51. |
87016
|
[2] |
WASHER,0.41" ID x 0.81" OD x 0.07" Thk
|
NH
|
| 52. |
47799321
|
[2] |
LINK,RC 2040, 25.4 Pitch
|
NH
|
| 53. |
9822495
|
[2] |
BUSHING,25.5mm ID x 31.82mm OD x 19.5mm L
|
NH
|
