| 1. |
47378464
|
[1] |
PLATE
|
NH
|
| 2. |
87025815
|
[1] |
SHIELD
|
PA
|
| 3. |
9608202
|
[1] |
HUB
|
PA
RH Superseded by part number: 86636673
|
| 4. |
9803281
|
[1] |
HUB
|
PA
LH Superseded by part number: 86636786
|
| 5. |
87398962
|
[2] |
HUB,12.5mm ID x 47.42mm OD x 13.2mm L
|
PA
|
| 6. |
86548973
|
[2] |
FLANGE
|
NH
Superseded by part number: 86620027
|
| 7. |
412441
|
[1] |
ROLLER BEARING,40mm ID x 80mm OD x 21mm W, Round Bore
|
PA
|
| 8. |
9803325
|
[2] |
SUPPORT
|
NH
|
| 9. |
14441231
|
[4] |
HEX SOC SCREW,Flat Csk Hd, M6 x 12mm, Cl 10.9
|
MKT
|
| 10. |
87052121
|
[2] |
GEAR
|
NH
24T
|
| 11. |
87611565
|
[1] |
ROLL
|
NH
Pivot
|
| 12. |
87396559
|
[1] |
ROLL
|
NH
Stripper
|
| 13. |
9808557
|
[1] |
BUSHING
|
PA
Superseded by part number: 86636893
|
| 14. |
86619670
|
[1] |
SHIELD
|
NH
|
| 15. |
9843938
|
[1] |
SHIELD
|
PA
Superseded by part number: 86637157
|
| 16. |
9806931
|
[1] |
IDLER GEAR,17T
|
NH
17T
|
| 17. |
9843939
|
[1] |
CAP
|
NH
|
| 18. |
84415463
|
[1] |
FLANGED BEARING
|
NH
|
| 19. |
84313928
|
[1] |
SHIELD
|
PLO
Trash
|
| 20. |
81972
|
[16] |
HEX SOC SCREW,5/16" - 18 x 1-3/4"
|
GI
|
| 21. |
168104
|
[2] |
SNAP RING,#177, Ext
|
GI
|
| 22. |
9628503
|
[4] |
NUT,3/8"-16, G5
|
NH
|
| 23. |
9804278
|
[2] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 24. |
9706693
|
[1] |
BOLT,M12 x 60mm, Cl 8.8
|
NH
|
| 25. |
9706687
|
[1] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 26. |
412087
|
[2] |
BOLT,Hex, M12 x 1.75 x 45mm, Cl 10.9, Full Thd
|
BHB
Superseded by part number: 86639031
|
| 27. |
88206
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
NH
|
| 28. |
88011
|
[1] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
|
NH
|
| 29. |
86516319
|
[1] |
PLOW BOLT,7/16" - 14 x 1 3/4", Gr 5
|
NH
|
| 30. |
280747
|
[1] |
BOLT,Hex, 7/16" - 14 x 1 3/4", Gr 5
|
WIN
Superseded by part number: 84192879
|
| 31. |
43140
|
[4] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 32. |
374892
|
[2] |
CARRIAGE BOLT,M10 x 1.5 x 40mm, Cl 8.8
|
NH
|
| 33. |
281004
|
[4] |
PLOW BOLT,#3, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
GI
|
| 34. |
140046
|
[1] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 35. |
140045
|
[4] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 36. |
80680
|
[4] |
LOCK WASHER,3/8 0.381 CST ZND
|
NH
|
| 37. |
81541
|
[4] |
WASHER,0.5" ID x 1.25" OD x 0.08" Thk
|
NH
|
| 38. |
29684
|
[2] |
WASHER,13.5mm ID x 50.8mm OD x 5.52mm Thk
|
NH
|
| 39. |
86527218
|
[1] |
CHAIN,378mm L
|
NH
|
| 40. |
9670066
|
[4] |
FLANGE BOLT,Hex, M12 x 30mm, Cl 8.8
|
NH
|
| 41. |
87517
|
[2] |
NUT,7/16"-14, GB
|
NH
Superseded by part number: 280980
|
| 42. |
120068
|
[2] |
BOLT,Hex, M10 x 40mm, Cl 8.8
|
NH
|
| 43. |
47638111
|
[1] |
WEAR PLATE
|
NH
LH
|
| 44. |
47638061
|
[1] |
WEAR PLATE
|
NH
RH
|
