现代零件查询15/18/20BT-7 RELIEF VALVE ASSY(NEW)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
834 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
XKBF-01118
|
[1] |
MAIN RELIEF VALVE
|
|
| . |
XKBF-01118
|
[1] |
MAIN RELIEF VALVE
|
|
| . |
XKBF-01118
|
[1] |
MAIN RELIEF VALVE
|
|
| . |
XKBF-01166
|
[1] |
SECONDARY RELIEF V/V
|
|
| . |
XKBF-01166
|
[1] |
SECONDARY RELIEF V/V
|
|
| . |
XKBF-01166
|
[1] |
SECONDARY RELIEF V/V
|
|
| N1. |
XKBF-01105
|
[1] |
PILOT SEAT
|
|
| K2. |
XKBF-01106
|
[1] |
O-RING
|
|
| N3. |
XKBF-01107
|
[1] |
MAIN POPPET
|
|
| NK4. |
XKBF-01108
|
[1] |
BACKUP RING
|
|
| NK5. |
XKBF-01109
|
[1] |
O-RING
|
|
| N6. |
XKBF-01110
|
[1] |
SOCKET
|
|
| N7. |
XKBF-01071
|
[1] |
MAIN SPRING
|
|
| N8. |
XKBF-01111
|
[1] |
PISTON
|
|
| N9. |
XKBF-01112
|
[1] |
BODY
|
|
| K10. |
XKBF-00989
|
[1] |
O-RING
|
|
| K11. |
XKBF-01113
|
[1] |
BACKUP RING
|
|
| K12. |
XKBF-00937
|
[1] |
O-RING
|
|
| N13. |
XKBF-01076
|
[1] |
PILOT POPPET
|
|
| N14. |
XKBF-01077
|
[1] |
PILOT SPRING
|
|
| N15. |
XKBF-01078
|
[1] |
ADJUST SCREW
|
|
| K16. |
XKBF-01079
|
[1] |
O-RING
|
|
| N17. |
XKBF-01080
|
[1] |
LOCK NUT
|
|
| K. |
XKBF-01114
|
[1] |
SEAL KIT
|
|
