凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (68.180.BB[01]) - TWINE KNIFE, P.I.N. YGN190999 AND AFTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
383 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47899142
|
[1] |
SUPPORT
|
NH
|
| 2. |
47934359
|
[1] |
PIVOT
|
NH
Mouint
|
| 3. |
617945
|
[1] |
KNIFE SECTION
|
NH
|
| 4. |
47899150
|
[1] |
GUIDE
|
NH
|
| 5. |
47899153
|
[1] |
ROD
|
NH
|
| 6. |
47899152
|
[1] |
SHIELD
|
NH
|
| 7. |
86512439
|
[4] |
CARRIAGE BOLT,M6 x 16mm, Cl 8.8
|
NH
|
| 8. |
353308
|
[2] |
NUT,M6 x 1.0, Cl 8
|
NH
|
| 9. |
9671714
|
[3] |
FLANGE BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 10. |
9804277
|
[3] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 11. |
9804276
|
[2] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 12. |
378244
|
[2] |
WASHER,10.5mm ID x 24mm OD x 2mm Thk
|
NH
|
| 13. |
80755
|
[1] |
COTTER PIN,1/8" OD x 1" L
|
NH
|
| 14. |
47907372
|
[1] |
SPRING
|
NH
|
| 15. |
83902308
|
[1] |
SNAP RING
|
A
Superseded by part number: 515259
|
