神钢零件查询(FD6T04) - NISSAN DIESEL ENGINE - LK500 (1/06-12/06) (06-001) - PUMP-FEED (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
501 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-21. | VG1664095000 | [1] | PUMP | KOBPUMP ASSY-FEED |
| 1. | VG1664199001 | [1] | HOUSING HOUSING | HOUSING HOUSING |
| 2. | VG1664537501 | [1] | PISTON | KOBPISTON Superseded by part number: 76602249 |
| 3. | VG1664637500 | [1] | SPRING | KOBSPRING-PISTON |
| 4. | VG1664737500 | [1] | PLUG-PISTON CHAMBER | |
| 5. | VG1665737500 | [1] | WASHER WASHER | WASHER WASHER |
| 6-9. | VG1664837504 | [1] | TAPPET ASSY | |
| 7. | VG1664937500 | [1] | ROLLER-TAPPET | |
| 8. | VG1665037501 | [1] | PIN-ROLLER | |
| 9. | VG1665137501 | [2] | GUIDE-TAPPET | |
| 10. | VG1665237500 | [2] | VALVE, CHECK VALVE-CHECK | VALVE, CHECK VALVE-CHECK |
| 11. | VG1665337500 | [2] | SPRING | KOBSPRING-CHECK VALVE |
| 12. | VG1665899000 | [1] | ADAPTER | |
| 13. | VG1666299000 | [1] | GASKET GASKET | GASKET GASKET |
| 14. | VG1927899010 | [1] | O-RING | KOBO-RING Superseded by part number: 76551189 |
| 15. | VG1666037500 | [1] | PISTON RING SET | KOBRING-SNAP, TAPPET Superseded by part number: 76602260 |
| 16. | VG1665537501 | [1] | PUMP | KOBPUMP-PRIMING Superseded by part number: 1665537501 |
| 17. | VG1665637500 | [1] | BOLT BOLT-PIPE JOINT | BOLT BOLT-PIPE JOINT |
| 19. | VG1666337500 | [1] | BOLT BOLT-PIPE JOINT | BOLT BOLT-PIPE JOINT |
| 20. | VG1666237500 | [4] | GASKET | |
| 21. | VG1664490000 | [1] | COVER | KOBCOVER, PRIMING PUMP |
