现代零件查询15/18/20BT-7 4-SPOOL HYDRAULIC PIPING (V-MAST)EPC Hyundai _现代Hyundai_工程机械

Pos.	Part No	Qty	Parts name	Comments
1.	P933-044027	[2]	HOSE ASSY-ORFS 0X90	15BT
1.	P933-043027	[2]	HOSE ASSY-ORFS 0X90	15BT
1.	P933-044027	[2]	HOSE ASSY-ORFS 0X90	18BT
1.	P933-043027	[2]	HOSE ASSY-ORFS 0X90	18BT
1.	P933-044027	[2]	HOSE ASSY-ORFS 0X90	20BT
1.	P933-043027	[2]	HOSE ASSY-ORFS 0X90	20BT
2.	P933-044030	[2]	HOSE ASSY-ORFS 0X90	15BT
2.	P933-043030	[2]	HOSE ASSY-ORFS 0X90	15BT
2.	P933-044030	[2]	HOSE ASSY-ORFS 0X90	18BT
2.	P933-043030	[2]	HOSE ASSY-ORFS 0X90	18BT
2.	P933-044030	[2]	HOSE ASSY-ORFS 0X90	20BT
2.	P933-043030	[2]	HOSE ASSY-ORFS 0X90	20BT
3.	P910-044040	[4]	HOSE ASSY-ORFS 0X0	V250,15BT
3.	P910-043040	[4]	HOSE ASSY-ORFS 0X0	V250,15BT
3.	P910-044040	[4]	HOSE ASSY-ORFS 0X0	V250,18BT
3.	P910-043040	[4]	HOSE ASSY-ORFS 0X0	V250,18BT
3.	P910-044040	[4]	HOSE ASSY-ORFS 0X0	V250,20BT
3.	P910-043040	[4]	HOSE ASSY-ORFS 0X0	V250,20BT
3.	P910-044044	[4]	HOSE ASSY-ORFS 0X0	V270,15BT
3.	P910-043044	[4]	HOSE ASSY-ORFS 0X0	V270,15BT
3.	P910-044044	[4]	HOSE ASSY-ORFS 0X0	V270,18BT
3.	P910-043044	[4]	HOSE ASSY-ORFS 0X0	V270,18BT
3.	P910-044044	[4]	HOSE ASSY-ORFS 0X0	V270,20BT
3.	P910-043044	[4]	HOSE ASSY-ORFS 0X0	V270,20BT
3.	P910-044050	[4]	HOSE ASSY-ORFS 0X0	V300,15BT
3.	P910-043050	[4]	HOSE ASSY-ORFS 0X0	V300,15BT
3.	P910-044050	[4]	HOSE ASSY-ORFS 0X0	V300,18BT
3.	P910-043050	[4]	HOSE ASSY-ORFS 0X0	V300,18BT
3.	P910-044050	[4]	HOSE ASSY-ORFS 0X0	V300,20BT
3.	P910-043050	[4]	HOSE ASSY-ORFS 0X0	V300,20BT
3.	P910-044056	[4]	HOSE ASSY-ORFS 0X0	V330,15BT
3.	P910-043056	[4]	HOSE ASSY-ORFS 0X0	V330,15BT
3.	P910-044056	[4]	HOSE ASSY-ORFS 0X0	V330,18BT
3.	P910-043056	[4]	HOSE ASSY-ORFS 0X0	V330,18BT
3.	P910-044056	[4]	HOSE ASSY-ORFS 0X0	V330,20BT
3.	P910-043056	[4]	HOSE ASSY-ORFS 0X0	V330,20BT
3.	P910-044060	[4]	HOSE ASSY-ORFS 0X0	V350,15BT
3.	P910-043060	[4]	HOSE ASSY-ORFS 0X0	V350,15BT
3.	P910-044060	[4]	HOSE ASSY-ORFS 0X0	V350,18BT
3.	P910-043060	[4]	HOSE ASSY-ORFS 0X0	V350,18BT
3.	P910-044060	[4]	HOSE ASSY-ORFS 0X0	V350,20BT
3.	P910-043060	[4]	HOSE ASSY-ORFS 0X0	V350,20BT
3.	P910-044064	[4]	HOSE ASSY-ORFS 0X0	V370,15BT
3.	P910-043064	[4]	HOSE ASSY-ORFS 0X0	V370,15BT
3.	P910-044064	[4]	HOSE ASSY-ORFS 0X0	V370,18BT
3.	P910-043064	[4]	HOSE ASSY-ORFS 0X0	V370,18BT
3.	P910-044064	[4]	HOSE ASSY-ORFS 0X0	V370,20BT
3.	P910-043064	[4]	HOSE ASSY-ORFS 0X0	V370,20BT
3.	P910-044070	[4]	HOSE ASSY-ORFS 0X0	V400,15BT
3.	P910-043070	[4]	HOSE ASSY-ORFS 0X0	V400,15BT
3.	P910-044070	[4]	HOSE ASSY-ORFS 0X0	V400,18BT
3.	P910-043070	[4]	HOSE ASSY-ORFS 0X0	V400,18BT
3.	P910-044070	[4]	HOSE ASSY-ORFS 0X0	V400,20BT
3.	P910-043070	[4]	HOSE ASSY-ORFS 0X0	V400,20BT
3.	P910-044084	[4]	HOSE ASSY-ORFS 0X0	V450,15BT
3.	P910-043084	[4]	HOSE ASSY-ORFS 0X0	V450,15BT
3.	P910-044084	[4]	HOSE ASSY-ORFS 0X0	V450,18BT
3.	P910-043084	[4]	HOSE ASSY-ORFS 0X0	V450,18BT
3.	P910-044084	[4]	HOSE ASSY-ORFS 0X0	V450,20BT
3.	P910-043084	[4]	HOSE ASSY-ORFS 0X0	V450,20BT
3.	P910-044094	[4]	HOSE ASSY-ORFS 0X0	V500,15BT
3.	P910-043094	[4]	HOSE ASSY-ORFS 0X0	V500,15BT
3.	P910-044094	[4]	HOSE ASSY-ORFS 0X0	V500,18BT
3.	P910-043094	[4]	HOSE ASSY-ORFS 0X0	V500,18BT
3.	P910-044094	[4]	HOSE ASSY-ORFS 0X0	V500,20BT
3.	P910-043094	[4]	HOSE ASSY-ORFS 0X0	V500,20BT
3.	P910-044104	[4]	HOSE ASSY-ORFS 0X0	V550,15BT
3.	P910-043104	[4]	HOSE ASSY-ORFS 0X0	V550,15BT
3.	P910-044104	[4]	HOSE ASSY-ORFS 0X0	V550,18BT
3.	P910-043104	[4]	HOSE ASSY-ORFS 0X0	V550,18BT
3.	P910-044104	[4]	HOSE ASSY-ORFS 0X0	V550,20BT
3.	P910-043104	[4]	HOSE ASSY-ORFS 0X0	V550,20BT
4.	31HH-80300	[2]	PULLEY-HOSE
5.	31FV-90130	[2]	PIN-HOSE PULLEY
6.	S017-120606	[2]	BOLT-HEX
7.	S411-120006	[2]	WASHER-SPRING
8.	S441-120006	[2]	WASHER-HARDENED
9.	X540-120001	[4]	CONNECTOR-ORFS
10.	X515-107523	[2]	CONNECTOR-LONG,ORFS	15BT
10.	31HG-90170	[2]	CONNECTOR	15BT
10.	X515-107523	[2]	CONNECTOR-LONG,ORFS	18BT
10.	31HG-90170	[2]	CONNECTOR	18BT
10.	X515-107523	[2]	CONNECTOR-LONG,ORFS	20BT
10.	31HG-90170	[2]	CONNECTOR	20BT
10-1.	S621-011001	[2]	O-RING	15BT
10-1.	S621-011001	[2]	O-RING	18BT
10-1.	S621-011001	[2]	O-RING	20BT
10-2.	S611-016001	[2]	O-RING	15BT
10-2.	S611-016001	[2]	O-RING	18BT
10-2.	S611-016001	[2]	O-RING	20BT
11.	33FY-90130	[2]	CONNECTOR	15BT
11.	31HG-90140	[2]	CONNECTOR	15BT
11.	33FY-90130	[2]	CONNECTOR	18BT
11.	31HG-90140	[2]	CONNECTOR	18BT
11.	33FY-90130	[2]	CONNECTOR	20BT
11.	31HG-90140	[2]	CONNECTOR	20BT
11-1.	S621-011001	[2]	O-RING	15BT
11-1.	S621-011001	[2]	O-RING	18BT
11-1.	S621-011001	[2]	O-RING	20BT
11-2.	S611-016001	[2]	O-RING	15BT
11-2.	S611-016001	[2]	O-RING	18BT
11-2.	S611-016001	[2]	O-RING	20BT
12.	S621-011001	[2]	O-RING	15BT
12.	S621-011001	[2]	O-RING	18BT
12.	S621-011001	[2]	O-RING	20BT
13.	S631-014001	[4]	O-RING	15BT
13.	S631-014001	[4]	O-RING	18BT
13.	S631-014001	[4]	O-RING	20BT
14.	31FY-90500	[4]	ELBOW WA	15BT
14.	31HN-90700	[4]	ELBOW-90,ORFS	15BT
14.	31FY-90500	[4]	ELBOW WA	18BT
14.	31HN-90700	[4]	ELBOW-90,ORFS	18BT
14.	31FY-90500	[4]	ELBOW WA	20BT
14.	31HN-90700	[4]	ELBOW-90,ORFS	20BT
15.	X710-100102	[4]	CAP-HYD,ORFS
16.	S552-102370	[8]	CLAMP-BAND
17.	33FP-90380-DA	[4]	NUT	15BT
17.	33FP-90380-DA	[4]	NUT	18BT
17.	33FP-90380-DA	[4]	NUT	20BT
18.	33FP-90200	[2]	CLAMP
19.	S035-063526	[4]	BOLT-W/WASHER
20.	61HH-18510	[2]	GUARD
21.	33FY-90610	[2]	CONNECTOR	FINGERTIP, 15BT
21.	33FY-90610	[2]	CONNECTOR	FINGERTIP, 18BT
21.	33FY-90610	[2]	CONNECTOR	FINGERTIP, 20BT
21-1.	S611-012001	[2]	O-RING	FINGERTIP, 15BT
21-1.	S611-012001	[2]	O-RING	FINGERTIP, 18BT
21-1.	S611-012001	[2]	O-RING	FINGERTIP, 20BT
21-2.	S621-011001	[2]	O-RING	FINGERTIP, 15BT
21-2.	S621-011001	[2]	O-RING	FINGERTIP, 18BT
21-2.	S621-011001	[2]	O-RING	FINGERTIP, 20BT
22.	33FY-90620	[2]	CONNECTOR	FINGERTIP, 15BT
22.	33FY-90620	[2]	CONNECTOR	FINGERTIP, 18BT
22.	33FY-90620	[2]	CONNECTOR	FINGERTIP, 20BT
22-1.	S611-012001	[2]	O-RING	FINGERTIP, 15BT
22-1.	S611-012001	[2]	O-RING	FINGERTIP, 18BT
22-1.	S611-012001	[2]	O-RING	FINGERTIP, 20BT
22-2.	S621-011001	[2]	O-RING	FINGERTIP, 15BT
22-2.	S621-011001	[2]	O-RING	FINGERTIP, 18BT
22-2.	S621-011001	[2]	O-RING	FINGERTIP, 20BT
