神钢零件查询(FD6T04) - NISSAN DIESEL ENGINE - LK500 (1/06-12/06) (07-002) - GENERATOR (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
497 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-27. | VG23100Z5509 | [1] | GENERATOR ASSY, FOR 41,46,47,51,56,57,72,76,81 ONLY | |
| 1-27. | VG23100Z5500 | [1] | GENERATOR(NO LONGER AVAILABLE) GENERATOR ASSY, FOR 71 ONLY | GENERATOR(NO LONGER AVAILABLE) GENERATOR ASSY, FOR 71 ONLY |
| 1-5. | VG2310899019 | [1] | ROTOR | KOBROTOR ASSY |
| 2-3. | VG2311799006 | [1] | RETAINER RETAINER-BEARING | RETAINER RETAINER-BEARING |
| 3. | VG2311699004 | [1] | PACKING | KOBPACKING |
| 4. | VG2312099010 | [1] | BALL BEARING | KOBBEARING-BALL |
| c. | VG2312099011 | [1] | BALL BEARING | KOBBEARING-BALL |
| 6. | VG2319590000 | [1] | KEY KEY-WOODRUFF | KEY KEY-WOODRUFF |
| 7. | VG2311099000 | [1] | SLIPPER | KOBRING-SLIP |
| 8. | VG2310299016 | [1] | STATOR | KOBSTARTER ASSY |
| 9-22. | VG23127Z9011 | [1] | COVER COVER ASSY-REAR | COVER COVER ASSY-REAR |
| 9. | VG2312899019 | [1] | COVER REAR COVER-REAR | COVER REAR COVER-REAR |
| 10-11. | VG2311499004 | [1] | HOLDER | KOBHOLDER ASSY-SR |
| 11. | VG2313790006 | [3] | DIODE | KOBDIODE |
| 12-13. | VG2311499005 | [1] | HOLDER | KOBHOLDER ASSY-SR |
| 13. | VG2313790007 | [3] | DIODE | KOBDIODE |
| 14. | VG2314699013 | [1] | TERMINAL | KOBTERMINAL ASSY |
| 15. | VG2313590010 | [1] | BRUSH | KOBBRUSH |
| 16. | VG23165Z9008 | [1] | WIRE WIRE ASSY-LEAD | WIRE WIRE ASSY-LEAD |
| 17. | VG2314699000 | [1] | COVER-TERMINAL | |
| 18. | VG2310799004 | [1] | COVER COVER-BRUSH | COVER COVER-BRUSH |
| 19. | VG2313899014 | [1] | SCREW SCREW SET | SCREW SCREW SET |
| 20. | VG2313899013 | [1] | SCREW SCREW SET | SCREW SCREW SET |
| 21. | VG2313899012 | [1] | SCREW | KOBSCREW SET |
| 22. | VG2314790007 | [1] | BOLT BOLT-TERMINAL | BOLT BOLT-TERMINAL |
| 23-24. | VG2311999013 | [1] | COVER ASSY COVER ASSY-FRONT | COVER ASSY COVER ASSY-FRONT |
| 24. | VG2312199001 | [1] | PACKING | KOBPACKING |
| 25. | VG23151Z9010 | [1] | PULLEY | KOBPULLEY ASSY-FAN, FOR 71 ONLY |
| 26. | VG2313178500 | [3] | BOLT BOLT-THROUGH | BOLT BOLT-THROUGH |
| 27. | VG2316199001 | [1] | NUT | KOBNUT ASSY-PULLEY |
