凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (88.100.39[01]) - DIA KIT, SAFETY, CHAIN Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
952 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84401639
|
[1] |
DIA KIT, HARVESTER
|
NH
Safety chain, Incl 2 - 8
|
| 2. |
84394650
|
[1] |
INSTRUCTION
|
NH
|
| 3. |
850116
|
[1] |
CHAIN
|
NH
|
| 4. |
86607695
|
[1] |
SPACER,17.48mm ID x 28.6mm OD x 20.6mm L
|
NH
|
| 5. |
362573
|
[1] |
BOLT,Hex, M16 x 150mm, Cl 8.8
|
NH
|
| 6. |
636422
|
[1] |
WASHER,16.66mm ID x 69.85mm OD
|
NH
|
| 7. |
130358
|
[3] |
WASHER,16.28mm ID x 38.35mm OD x 4.11mm Thk
|
NH
|
| 8. |
86000441
|
[1] |
NUT,M16 x 2.0, Cl 8
|
NH
|
