纽荷兰零件查询(D95B) - CRAWLER DOZER TIER 3 (3/08-) (09-45) - CAB - SCREEN, REAR New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
975 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87543873 | [1] | SCREEN | BURRear Cab Screen |
| 2. | 87623643 | [1] | SUPPORT | BURRear Cab |
| 3. | 814-8090 | [2] | BOLT,Hex, M8 x 1.25 x 90mm, Cl 8.8 | CAS Superseded by part number: 86508571 |
| 4. | 895-15008 | [4] | WASHER,M8 x 20 x 1.6 | CAS Superseded by part number: 86625263 |
| 5. | 832-10408 | [2] | NUT,M8 x 1.25, Cl 8 | CAS Superseded by part number: 86528579 |
| 6. | 614-10025 | [4] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8 | CAS Superseded by part number: 11106231 |
| 7. | 895-15010 | [4] | WASHER,M11 x 24 x 2 | CAS Superseded by part number: 86625253 |
| 8. | 122958A1 | [2] | SQUARE NUT | CASSquare, M10 Superseded by part number: 230427A1 |
| 9. | 336371A1 | [2] | PIN | CASNut Retainer |
| 10. | 87543876 | [1] | SUPPORT | BURScreen Prop Support |
| 11. | 614-10030 | [2] | BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd | IH Superseded by part number: 43140 |
| 13. | 832-10410 | [1] | NUT,M10 x 1.5, Cl 8 | CAS Superseded by part number: 190003888452 |
| 14. | 614-12035 | [4] | BOLT,Hex, M12 x 1.75 x 35mm, Cl 8.8, Full Thd | IH |
| 15. | 892-11012 | [4] | LOCK WASHER,M12 | CAS Superseded by part number: 412123 |
| 16. | 896-11012 | [4] | WASHER,13.5mm ID x 24mm OD x 3mm Thk | CAS Superseded by part number: 86625255 |
| 17. | N7673 | [1] | BUMPER | CAS Superseded by part number: 84541962 |
| 18. | 495-11034 | [1] | WASHER,5/16", SAE | CAS Superseded by part number: 80701, 72187257 |
| 19. | 231-1445 | [1] | NUT,5/16"-18, GB | CAS Superseded by part number: 86050277 |
