神钢零件查询(FD6T04) - NISSAN DIESEL ENGINE - LK500 (1/06-12/06) (04-002[02]) - FILTER-OIL (FITTING PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
881 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VG15200Z5002 | [1] | FILTER ASSY-OIL (INNER PARTS 04-003), FOR 41,46,47,51,56,57,76,81 ONLY | |
| 1. | VG15200Z5501 | [1] | FILTER ASSY | KOBFILTER ASSY-OIL (INNER PARTS 04-003), FOR 71 ONLY |
| 1. | VG15200Z5504 | [1] | FILTER ASSY-OIL (INNER PARTS 04-003), FOR 72 ONLY | |
| 2. | VG2138790001 | [2] | RUBBER RING | KOBRING-RUBBER |
| 3. | VG0811107510 | [2] | BOLT BOLT | BOLT BOLT |
| 4. | VG0811106010 | [2] | BOLT BOLT | BOLT BOLT |
| 5. | VG0891514010 | [4] | WASHER WASHER-SPRING | WASHER WASHER-SPRING |
| 6. | VG15068Z5000 | [1] | CONNECTOR-OIL, FOR 41,46,47,51,56,57,72,76,81 ONLY | |
| 6. | VG15068Z5501 | [1] | CONNECTOR CONNECTOR-OIL, FOR 71 ONLY | CONNECTOR CONNECTOR-OIL, FOR 71 ONLY |
| 7. | VG11072Z5500 | [1] | O-RING O RING | O-RING O RING |
| 8. | VG2130661520 | [1] | RING | KOBO RING |
| 9. | VG0811080010 | [1] | BOLT BOLT | BOLT BOLT |
| 10. | VG0891513810 | [1] | WASHER SPRING WASHER-SPRING | WASHER SPRING WASHER-SPRING |
| 11. | VG0811082062 | [1] | BOLT | KOBBOLT, W/WASHER |
