凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (88.100.62[04]) - DIA KIT, HIGH MOISTURE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
779 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47465658
|
[1] |
DIA KIT, HARVESTER
|
NH
High Moisture Incl 2 - 13 Superseded by part number: 47883693
|
| 2. |
84401905
|
[1] |
INSTRUCTION
|
NH
|
| 3. |
47465281
|
[1] |
SUPPORT
|
NH
|
| 4. |
86637004
|
[2] |
SCRAPER BLADE
|
NH
|
| 5. |
47761419
|
[1] |
SUPPORT
|
NH
|
| 6. |
308761
|
[18] |
CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 7. |
322358
|
[18] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 8. |
9804277
|
[8] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 9. |
381014
|
[10] |
SCREW,Flng, M8 x 16mm
|
NH
|
| 10. |
86512446
|
[4] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 11. |
9804278
|
[4] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 12. |
86629542
|
[10] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 13. |
80664
|
[10] |
WASHER,0.38" ID x 0.88" OD x 0.08" Thk
|
NH
|
