神钢零件查询(FD6T04) - NISSAN DIESEL ENGINE - LK500 (1/06-12/06) (05-002) - NOZZLE & HOLDER (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
740 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-12. | VG16600Z5506 | [1] | NOZZLE & HOLDER ASSY, FOR 41,46,47 ONLY | |
| 1-12. | VG16600Z5508 | [1] | NOZZLE | KOBNOZZLE & HOLDER ASSY, FOR 51,56,57,71,72,76,81 ONLY |
| 1-11. | VG16610Z5502 | [1] | HOLDER | KOBHOLDER ASSY |
| 2. | VG1660896000 | [1] | PIN | KOBPIN |
| 3. | VG1661296000 | [1] | PUSH ROD | KOBROD-PUSH |
| 4. | VG1661490000 | [1] | SPRING SEAT | KOBSEAT-SPRING |
| 5. | VG16613Z9000 | [1] | SPRING | KOBSPRING |
| 6. | VG1661690001 | [1] | SCREW SCREW | SCREW SCREW |
| 7. | VG1660996000 | [1] | PIN | KOBNUT-CAP |
| 8. | VG1665799004 | [1] | GASKET | KOBGASKET |
| 9. | VG16629Z9001 | [1] | RETAINER | KOBNUT-RETAINING |
| 10. | VG16657Z9000 | [1] | GASKET | KOBGASKET |
| 11. | VG16619Z9000 | [1] | CONNECTOR CONNECTOR | CONNECTOR CONNECTOR |
| 12. | VG16620Z5504 | [1] | NOZZLE | KOBNOZZLE ASSY, FOR 41,46,47 ONLY |
| 12. | VG16620Z5505 | [1] | NOZZLE | KOBNOZZLE ASSY, FOR 51,56,57,71,72,76,81 ONLY |
