神钢零件查询(FD6T04) - NISSAN DIESEL ENGINE - LK500 (1/06-12/06) (08-004) - SHAFT-POWER CONDUCTION Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
441 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VG3224195001 | [1] | SHAFT-DRIVE | |
| 2. | VG3211295000 | [1] | HOLDER-BEARING | |
| 3. | VG4021150000 | [2] | BEARING-ROLLER | |
| 4. | VG3220695000 | [1] | RING-DESTANCE | |
| 5. | VG3220790000 | [1] | NUT-LOCK | |
| 6. | VG3220890000 | [1] | WASHER-LOCK | |
| 7. | VG3220999900 | [1] | RING-FELT | |
| 8. | VG0093210100 | [1] | FITTING | KOBNIPPLE-GREASE |
| 9. | VG0812443510 | [6] | BOLT | |
| 10. | VG0891514410 | [6] | WASHER WASHER-SPRING | WASHER WASHER-SPRING |
| 11. | VG3211495000 | [1] | RETAINER-BEARING | |
| 12. | VG3211895000 | [1] | SHIM-RETAINER (T=0.50) | |
| 12. | VG3211895001 | [1] | SHIM-RETAINER (T=0.15) | |
| 12. | VG3211895002 | [1] | SHIM-RETAINER (T=0.10) | |
| 13. | VG0811403062 | [4] | BOLT, W/WASHER | |
| 14. | VG3211995000 | [1] | SEAL-OIL | |
