凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (90.105.BH[03]) - DOOR LATCH Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
254 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84542881
|
[1] |
LATCH
|
NH
RH Superseded by part number: 47419812
|
| 1. |
84375213
|
[1] |
LATCH
|
NH
LH Superseded by part number: 47419812
|
| 2. |
87711617
|
[1] |
BRACKET
|
GI
|
| 3. |
87109697
|
[1] |
SPRING
|
GI
|
| 4. |
87701158
|
[1] |
LATCH ASSY.
|
GI
|
| 5. |
86511842
|
[2] |
BOLT,M8 x 1.25 x 48.1mm OAL, Cl 8.8
|
NH
|
| 6. |
9804277
|
[2] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 7. |
84542874
|
[1] |
HANDLE
|
NH
|
| 8. |
86588501
|
[1] |
WASHER,11mm ID x 20mm OD x 2.5mm Thk
|
GI
|
| 9. |
280250
|
[1] |
COTTER PIN,3/32" OD x 3/4" L
|
NH
|
