神钢零件查询(NE6(T)04) - NISSAN DIESEL ENGINE (1/86-12/98) (01-005) - MOUNTING ENGINE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
987 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 41 | [1] | SCREW | IHSPRING CLIP TADANO LTD. |
| 1. | VG1124695006 | [2] | BRACKET-FRONT | |
| 2. | VG081212301A | [8] | BOLT (NOT FOR SALE INDIVIDUALLY) | |
| 3. | VG089151421A | [8] | WASHER | KOBWASHER-SPRING ( NOT FOR SALE INDIVIDUALLY) |
| 4. | VG11223C2800 | [2] | CUSHION-RUBBER | |
| 5. | VG081244301A | [2] | BOLT ( NOT FOR SALE INDIVIDUALLY) | |
| 6. | VG089154441A | [2] | LOCK WASHER | KOBWASHER-PLAIN ( NOT FOR SALE INDIVIDUALLY) |
| 7. | VG11324C0501 | [2] | BRACKET-REAR MOUNT | |
| 8. | VG0822722510 | [8] | SCREW | KOBSTUD |
| 9. | VG089112421A | [8] | NUT NUT ( NOT FOR SALE INDIVIDUALLY) | NUT NUT ( NOT FOR SALE INDIVIDUALLY) |
| 10. | VG089151421A | [8] | WASHER | KOBWASHER-SPRING (NOT FOR SALE INDIVIDUALLY) |
| 11. | VG11327C0501 | [2] | CUSHION-RUBBER | |
| 12. | VG081242201A | [4] | BOLT ( NOT FOR SALE INDIVIDUALLY) | |
| 13. | VG0131100014 | [4] | WASHER-PLAIN | |
| 14. | VG089151421A | [4] | WASHER | KOBWASHER-SPRING (NOT FOR SALE INDIVIDUALLY) |
