纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (02-34) - CONNECTING ROD New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
449 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2831298 | [6] | CONNECTING ROD | TORAssembly; Incl. Ref 2, 3; Also Includes Cap Which Is Not Serviced Separately |
| . . | 2831298R | [6] | REMAN-CONNECTING ROD | TORD150B Tier 3 Hydro (10/07 - ) |
| . . | 2831298C | [1] | CORE-ROD CONNECTING | TORReturn Number |
| 2. | 4892708 | [1] | BUSHING,38.02mm ID x 41.01mm OD x 33.4mm L | TOR |
| 3. | 2831297 | [2] | FLANGE BOLT,Hex, M10 x 1.25 x 52mm, Cl 10.9 | TOR |
| 4. | 4892715 | [6] | BEARING LINER | TORBEARING, CON. ROD |
