现代零件查询15PA/40TA-7 FRAME(40TA)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
1005 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
41HB-02014
|
[1] |
MAIN FRAME WA
|
|
| 1. |
41HB-02015
|
[1] |
MAIN FRAME WA
|
|
| 2. |
41HB-00022
|
[1] |
PLATFORM WA
|
|
| 3. |
41HB-12271
|
[1] |
WEIGHT
|
|
| 4. |
6600212700B-01
|
[1] |
CHAIN-LINK
|
|
| 5. |
S035-082026
|
[1] |
BOLT-W/WASHER
|
|
| 6. |
41HB-12280
|
[1] |
BRACKET WA
|
|
| 7. |
S037-123526
|
[4] |
BOLT-W/WASHER
|
|
| 7. |
S037-123526
|
[6] |
BOLT-W/WASHER
|
|
| 9. |
41HB-12291
|
[1] |
SIDE SUPPORT WA(LH)-BATT
|
|
| 10. |
41HB-15100
|
[1] |
BUMPER WA
|
|
| 11. |
41HB-15201
|
[1] |
TOWING ASSY
|
|
| 11-1. |
41HB-15300
|
[1] |
TOWING BKT
|
|
| 11-2. |
41HB-15500
|
[1] |
TOWING PIN W.A
|
|
| 11-3. |
41HB-15600
|
[1] |
MIDDLE LEVER W.A
|
|
| 11-4. |
41HB-15701
|
[1] |
LEVER W.A
|
|
| 11-5. |
41HB-15800
|
[2] |
LINK
|
|
| 11-6. |
S741-302542
|
[2] |
FLANGE DU BUSH
|
|
| 11-7. |
S601-030006
|
[2] |
RING-RETAINING,C TYPE
|
|
| 11-8. |
S403-302006
|
[2] |
WASHER-PLAIN
|
|
| 11-9. |
S017-120306
|
[1] |
BOLT-HEX
|
|
| 11-10. |
S403-122006
|
[1] |
WASHER-PLAIN
|
|
| 11-11. |
S411-120006
|
[1] |
WASHER-SPRING
|
|
| 11-12. |
41HB-15810
|
[2] |
PIN
|
|
| 11-13. |
S601-015006
|
[4] |
RING-RETAINING,C TYPE
|
|
| 11-14. |
S471-600402
|
[1] |
PIN-SPRING
|
|
| 11-15. |
S651-810008
|
[1] |
NIPPLE-GREASE
|
|
