| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 41 | [1] | SCREW | IHSPRING CLIP TADANO LTD. |
| . . | 66 | [1] | KAWASAKI JUKO | KAWASAKI JUKO |
| . . | 71 | [1] | KOBE SEIKOJO | KOBE SEIKOJO |
| . . | 76 | [1] | FUJI JUKO | |
| . . | 77 | [1] | ORIENT ENGINEERING | |
| . . | 78 | [1] | ISHIKAWAJIMA KENKI | |
| 1. | VG1300195001 | [1] | CAMSHAFT | KOBCAMSHAFT |
| 2. | VG1301095001 | [1] | PLATE-CAMSHAFT, Start Year: 01-APR-86 | |
| 2. | VG1301095000 | [1] | PLATE-CAMSHAFT | |
| 3. | VG081108161B | [2] | SCREW | KOBBOLT.W/WASHER (NOT FOR SALE INDIVIDUALY) |
| 4. | VG0092662500 | [1] | KEY | KOBKEY-WOODRUFF |
| 5. | VG1302496000 | [1] | GEAR | KOBGEAR-CAMSHAFT |
| 6. | VG089154541A | [1] | LOCK WASHER | KOBWASHER-PLAIN (NOT FOR SALE INDIVIDUALY) |
| 7. | VG1302696000 | [1] | WASHER | KOBWASHER-SPRING |
| 8. | VG1301796000 | [1] | NUT | KOBNUT |
| 10. | VG1320195005 | [6] | VALVE-INLET,FOR 41 ONLY | |
| 10. | VG1320195006 | [6] | VALVE | KOBVALVE-INLET,FOR 66,71,76,77,78 ONLY |
| 11. | VG1320295003 | [6] | VALVE | KOBVALVE-EXHAUST |
| 12. | VG1320395002 | [12] | SPRING SPRING-VALVE, OUTER | SPRING SPRING-VALVE, OUTER |
| 13. | VG1320495003 | [12] | SPRING SPRING-VALVE, INNER | SPRING SPRING-VALVE, INNER |
| 14. | VG1320795002 | [12] | SEAT-VALVE SPRING (LOWER) | |
| 15. | VG1320995003 | [12] | SEAT-VALVE SPRING (UPPER) (NOT FOR SALE INDIVIDUALY), Start Year: 01-MAY-88 | |
| 15. | VG1320995002 | [12] | SEAT SEAT-VALVE SPRING (UPPER) | SEAT SEAT-VALVE SPRING (UPPER) |
| 16. | VG1320795003 | [12] | SEAL | KOBSEAL-VALVE STEM Superseded by part number: VG1320797062 |
| 17. | VG1320895003 | [24] | COLLAR SPLIT COLLAR-SPLIT | COLLAR SPLIT COLLAR-SPLIT |
| 20. | VG1325295000 | [2] | SHAFT | KOBSHAFT-ROCKER |
| 21. | VG1322195001 | [4] | BRACKET-A.ROCKER | |
| 22. | VG1322295001 | [2] | BRACKET-B,ROCKER | |
| 23. | VG1323696000 | [2] | SET SCREW | KOBBOLT-STOPPER |
| 24.25. | VG1326195001 | [12] | ROCKER ARM | KOBROCKER ASSY-VALVE |
| 25. | VG1326095000 | [12] | BUSHING | KOBBUSHING-ROCKER |
| 26. | VG1328996000 | [4] | WASHER | KOBSPACER |
| Z7. | VG1325596000 | [4] | CIRCLIP | KOBCIRCRIP |
| 28. | VG1325696000 | [4] | SPRING | KOBSPRING-INSIDE |
| 29. | VG13287J6500 | [12] | SCREW | KOBSCREW-ADJUST |
| 30. | VG1328896000 | [12] | NUT | KOBNUT |
| 31. | VG0112100094 | [12] | BOLT BOLT.W/WASHER | BOLT BOLT.W/WASHER |
| 32. | VG1323895001 | [12] | PUSH ROD | KOBROD-PUSH (NOT FOR SALE INDIVIDUALY), Start Year: 01-MAY-88 |
| 32. | VG1323895000 | [12] | PUSH ROD | KOBROD-PUSH |
| 33. | VG1323195002 | [12] | FOLLOWER-CAM (NOT FOR SALE INDIVIDUALY), Start Year: 01-MAY-88 | |
| 33. | VG1323195001 | [12] | FOLLOWER FOLLOWER-CAM | FOLLOWER FOLLOWER-CAM |
