纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (04-08) - HARNESS, EQUIPMENT CONTROL & MASTER DISCONNECT SWITCH New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
650 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87569871 | [1] | HARNESS | BUREquipment Control; To Valves, Filters, Brake Valve, and Backup Alarm |
| 2. | L18331 | [1] | CABLE TIE,375.9mm L | CAS Superseded by part number: 529070 |
| 3. | 515-23143 | [3] | CLAMP,9/16", Insul, 3/8" Bolt | CASInsulated 19.0 mm, M10 Bolt Superseded by part number: 72187280, 257492 |
| 6. | 87409316 | [1] | SWITCH | IMOMaster Disconnect; Component Parts Not Serviced Separately; Replaces R52278; Also See Figure 04-04 |
| 7. | 87533236 | [2] | GROUND CABLE | BURGround Cable |
| 8. | 832-46408 | [1] | NUT,M8 x 1.25, Cl 8 | CAS Superseded by part number: 86528579 |
| 9. | 614-10016 | [1] | BOLT,Hex, M10 x 1.5 x 16mm, Cl 8.8, Full Thd | CAS Superseded by part number: 300383 |
| 10. | 893-11010 | [1] | LOCK WASHER,Ext Tooth, M10 | CAS Superseded by part number: 86632602 |
| 11. | 614-10020 | [3] | BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd | CAS Superseded by part number: 43138 |
| 12. | 515-23127 | [3] | CLAMP,1/2", Insul, 3/8" Bolt | CASInsulated (12.7 mm) Superseded by part number: 86010402 |
| 13. | 87620402 | [2] | BOOT | BURElectrical |
